– 96 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MISCELLANEOUS
**************
64 1-773-188-11 WIRE (FLAT TYPE) (23 CORE)
104 1-773-042-11 WIRE (FLAT TYPE) (17 CORE)
105 1-773-024-11 WIRE (FLAT TYPE) (15 CORE)
106 1-783-570-11 WIRE (FLAT TYPE) (19 CORE)
109 1-769-977-11 WIRE (FLAT TYPE) (13 CORE)
(GRX50: EXCEPT SP, TW/RXD7: CND)
109 1-773-009-11 WIRE (FLAT TYPE) (15 CORE)
(GRX50: SP, TW/R770/RXD7: AEP)
110 1-233-544-14 TUNER PACK (RXD7: CND)
110 1-233-545-11 TUNER (FM/AM) (GRX50: EA4, TH, AR, AUS)
110 1-233-545-14 TUNER PACK (GRX50: E2, MX)
110 1-233-546-11 TUNER (FM/MW/SW)
(GRX50: E3, EA3, SP, TW)
110 1-693-443-11 TUNER (FM/AM) (R770/RXD7: AEP)
! 111 1-575-651-11 CORD, POWER (R770: AEP/RXD7: AEP, UK/
GRX50: EA3, EA4, SP, TW, AR)
! 111 1-575-653-11 CORD, POWER (GRX50: E2, E3, TH, MX)
! 111 1-690-608-11 CORD, POWER (GRX50: AUS)
! 111 1-690-609-21 CORD, POWER (RXD7: CND)
! 111 1-769-079-21 CORD, POWER (GRX50: KR)
! 112 1-569-007-11 ADAPTOR, CONVERSION 2P (GRX50: E3)
! 112 1-569-008-21 ADAPTOR, CONVERSION 2P
(GRX50: EA3, SP, TW)
257 1-452-925-21 MAGNET ASSY
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
! 301 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-NP
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
HP101 A-2056-681-A DECK (A) ASSY, HEAD
HRPE101A-2056-682-A DECK (B) ASSY, HEAD
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M501 1-698-792-11 FAN, DC (EXCEPT CND)
M801 A-4672-004-A MOTOR ASSY (SLIDE)
S811 1-473-335-11 ENCODER, ROTARY (BU, TRAY ADDRESS DET)
! T11 1-433-587-11 TRANSFORMER, POWER (RXD7: CND)
! T11 1-433-588-11 TRANSFORMER, POWER (R770/RXD7: AEP)
! T951 1-433-563-11 TRANSFORMER, POWER (RXD7: CND)
! T951 1-433-564-11 TRANSFORMER, POWER (R770/RXD7: AEP)
! T951 1-433-565-11 TRANSFORMER, POWER (GRX50)
************************************************************
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Sony Corporation
Home A&V Products Company
9-928-806-11
99B0575-1
Printed in Japan © 1999. 2
Published by Quality Assurance Dept.
(Shinagawa)
HCD-GRX50/R770/RXD7
**************
HARDWARE LIST
**************
#1 7-685-872-09 SCREW +BVTT 3X8 (S)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-871-01 SCREW +BVTT 3X6 (S)
#4 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#5 7-685-852-04 SCREW +BVTT 2X5 (S)
#6 7-685-861-01 SCREW +BVTT 2.6X5 (S)
#7 7-685-851-04 SCREW +BVTT 2X4 (S)
#8 7-621-775-10 SCREW +B 2.6X4
#9 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#10 7-685-880-09 SCREW +BVTT 4X6 (S)
#11 7-628-254-15 SCREW +PS 2.6X6
#12 7-628-254-50 SCREW +PS 2.6X16
