HCD-GTR33/GTR55/GTR77
SECTION 8
ELECTRICAL PARTS LIST
DISPLAY BOARD
*************
< CAPACITOR >
C1136 1-124-257-00 ELECT 2.2uF 20% 50V
C1137 1-124-257-00 ELECT 2.2uF 20% 50V
C1147 1-128-131-11 ELECT 22uF 20% 50V
C1150 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1151 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1152 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1153 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1155 1-126-947-11 ELECT 47uF 20% 35V
C1156 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN1102 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN1103 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN1105 1-784-784-11 CONNECTOR, FFC 23P
< DIODE >
D1101 6-502-469-01 DI SLI-325URT31WR
D1102 6-501-752-01 DIODE MAZ8082GMLS0
D1104 8-719-060-27 DIODE SLR-325MCT31
D1105 6-503-224-01 DI 1L0351V22F0MIT01
D1106 6-503-224-01 DI 1L0351V22F0MIT01
D1107 6-503-224-01 DI 1L0351V22F0MIT01
D1108 6-503-224-01 DI 1L0351V22F0MIT01
D1109 6-503-224-01 DI 1L0351V22F0MIT01
D1110 6-503-224-01 DI 1L0351V22F0MIT01
< FLUORESCENT INDICATOR TUBE >
FL1100 1-483-077-11 VACUUM FLUORESCENT DISPLAYS
< IC >
IC1100 6-600-768-01 IC PNA4823M03S0
IC1101 6-713-680-01 IC PT6324-Q
< JUMPER RESISTOR >
JR1001 1-216-295-91 SHORT CHIP 0
JR1002 1-216-864-11 SHORT CHIP 0
JR1003 1-216-295-91 SHORT CHIP 0
JR1004 1-216-296-11 SHORT CHIP 0
JR1005 1-216-296-11 SHORT CHIP 0
JR1006 1-216-296-11 SHORT CHIP 0
JR1007 1-216-296-11 SHORT CHIP 0
JR1008 1-216-295-91 SHORT CHIP 0
JR1009 1-216-296-11 SHORT CHIP 0
JR1010 1-216-296-11 SHORT CHIP 0
JR1011 1-216-296-11 SHORT CHIP 0
JR1012 1-216-296-11 SHORT CHIP 0
JR1013 1-216-296-11 SHORT CHIP 0
JR1014 1-216-864-11 SHORT CHIP 0
JR1015 1-216-296-11 SHORT CHIP 0
JR1016 1-216-296-11 SHORT CHIP 0
JR1017 1-216-296-11 SHORT CHIP 0
JR1018 1-216-296-11 SHORT CHIP 0
JR1019 1-216-296-11 SHORT CHIP 0
JR1020 1-216-296-11 SHORT CHIP 0
JR1021 1-216-296-11 SHORT CHIP 0
JR1022 1-216-296-11 SHORT CHIP 0
JR1023 1-216-864-11 SHORT CHIP 0
JR1024 1-216-296-11 SHORT CHIP 0
JR1025 1-216-296-11 SHORT CHIP 0
JR1026 1-216-296-11 SHORT CHIP 0
JR1027 1-216-296-11 SHORT CHIP 0
JR1028 1-216-296-11 SHORT CHIP 0
JR1029 1-216-296-11 SHORT CHIP 0
JR1030 1-216-296-11 SHORT CHIP 0
JR1031 1-216-296-11 SHORT CHIP 0
JR1032 1-216-296-11 SHORT CHIP 0
JR1033 1-216-296-11 SHORT CHIP 0
JR1034 1-216-296-11 SHORT CHIP 0
JR1035 1-216-864-11 SHORT CHIP 0
JR1036 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q1118 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1119 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1120 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1121 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1122 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R1100 1-216-819-11 METAL CHIP 680 5% 1/10W
R1101 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1102 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1103 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1104 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1105 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1106 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AR : Argentine model
E2 : 120V AC area in E model
E4 : African model
E51 : Chilean and Peruvian models
MX : Mexican model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
DISPLAY
To Next Page
