Sony HCD-GTR77 - Front Panel Block, HUB Board, DMB19 Board; DC Fan (M101), Back Panel

HCD-GTR33/GTR55/GTR77
7
2-6. DC FAN (M101), BACK PANEL
q; wire (flat type) (9 core)
(CN220)
qk binding band (taiton)
qa CN901 (3P)
ql clamp filter
(ferrite core)
wa back panel
qj tuner (FM/AM)
qh two screws
(BVTT3 u 6)
qs two screws
(BVTP3 u 8)
6 power cord
qd one screw
(BVTP3 u 8)
qf one screw
(BVTP3 u 8)
w; cord bush
qg
2 three screws
(BVTP3 u 8)
3 one screw
(BVTP3 u 8)
5 cover (fan)
4 one screw
(BVTP3 u 8)
1 three screws
(BVTP3 u 8)
7 two screws
(BVTP3 u 10)
8 CN690 (3P)
9 DC fan
2-5. FRONT PANEL BLOCK, HUB BOARD, DMB19 BOARD
wf DMB19 board: CN1105 (4P)/
HUB board: CN1500 (4P)
wa two screws
(BVTP3 u8)
qj CD block
ws HUB
board
2 two screws
(BVTP3 u10)
wg four screws
(BVTP3 u8)
7 wire (flat type) (9 core)
(CN1106)
wh DMB19 board
wd bracket
(ground hub)
ql CN201 (6P)
qk wire (flat type) (24 core)
(CN101)
8 DMB19 board:
CN601 (9P)
9 wire (flat type) (7 core)
(CN4602)
w; saranet cushion
5 wire (flat type) (23 core)
(CN405)
3 one screw
(BVTP3 u 10)
qh front panel block
qf panel loading
1 six screws
(BVTP3 × 8)
3 one screw
(BVTP3 × 10)
qg CN1501 (10P)
6 CN470 (7P)
4 wire (flat type) (11 core) (CN403)
qa wire (flat type) (13 core) (CN410)
q; CN1502 (7P)
lever
qs Turn a gear by
a driver till a lever
rises up to the
position of the figure.
state of opening the CD tray
gear
qd Pull the tray by hand.
