Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GTR33/GTR55/GTR77
60
C198 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C199 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C203 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C205 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C206 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C208 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C209 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C210 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C211 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C212 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C213 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C214 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C215 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C216 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C217 1-117-681-11 ELECT CHIP 100uF 20% 16V
C218 1-128-994-21 ELECT CHIP 47uF 20% 10V
C219 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C220 1-128-994-21 ELECT CHIP 47uF 20% 10V
C221 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C222 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C224 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C233 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C502 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C602 1-128-995-21 ELECT CHIP 100uF 20% 10V
C603 1-128-995-21 ELECT CHIP 100uF 20% 10V
C604 1-128-995-21 ELECT CHIP 100uF 20% 10V
C608 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C611 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C620 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C621 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C622 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C623 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C1504 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1506 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1507 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1512 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1513 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1514 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1515 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1516 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C4602 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C4603 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C4606 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C4608 1-124-779-00 ELECT CHIP 10uF 20% 16V
C4622 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4623 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4626 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN101 1-815-763-32 CONNECTOR, FFC/FPC 24P
CN105 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN201 1-770-161-21 PIN, CONNECTOR (PC BOARD) 6P
CN601 1-778-795-21 PIN, CONNECTOR (PC BOARD) 9P
* CN1105 1-750-005-11 PIN, CONNECTOR (PC BOARD) 4P
CN1106 1-784-861-51 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
CN4602 1-784-859-51 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< DIODE >
D001 6-500-848-01 DIODE MC2840-T112-1
D002 6-500-848-01 DIODE MC2840-T112-1
D003 6-500-848-01 DIODE MC2840-T112-1
D004 6-500-848-01 DIODE MC2840-T112-1
D005 6-500-848-01 DIODE MC2840-T112-1
< EARTH TERMINAL >
ET001 1-780-482-11 EARTH TERMINAL
ET002 1-780-482-11 EARTH TERMINAL
ET003 1-780-482-11 EARTH TERMINAL
ET004 1-780-482-11 EARTH TERMINAL
< FERRITE BEAD >
FB108 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB603 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB607 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1264 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1265 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1266 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1267 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1268 1-469-118-21 FERRITE, EMI (SMD) (1608)
< FLUORESCENT INDICATOR TUBE >
FL603 1-234-494-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC101 6-714-821-01 IC CXD9968R (LE)
IC102 (Not supplied) IC MX25L1605DM2I-12G
IC104 6-714-642-01 IC EM638165 TSA-6G
IC107 6-702-302-01 IC TK11133CSCL-G
IC111 6-706-838-01 IC MM1661JHBE
IC201 6-704-524-01 IC FAN8036L
IC4601 6-710-554-01 IC PCM1808PWR
IC4602 6-704-819-01 IC CS4335-KSZR
< TRANSISTOR >
Q101 6-550-008-01 TRANSISTOR UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-027-52 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-864-11 SHORT CHIP 0
R103 1-218-864-11 METAL CHIP 5.1K 0.5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-857-11 METAL CHIP 1M 5% 1/10W
R109 1-216-809-11 METAL CHIP 100 5% 1/10W
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-801-11 METAL CHIP 22 5% 1/10W
DMB19
Note: When IC102 cannot exchange with single. When this part
is damaged, exchange the entire mounted board.
