Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GTR33/GTR55/GTR77
68
< VIBRATOR >
X401 1-760-252-12 RELAY (32.768kHz)
X402 1-781-472-21 VIBRATOR, CERAMIC (8MHz)
*************************************************************
MIC BOARD
*********
< CAPACITOR >
C700 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C701 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C702 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C707 1-124-257-00 ELECT 2.2uF 20% 50V
C708 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C709 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C710 1-126-157-11 ELECT 10uF 20% 16V
C711 1-124-584-00 ELECT 100uF 20% 6.3V
C712 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C713 1-124-257-00 ELECT 2.2uF 20% 50V
C716 1-124-257-00 ELECT 2.2uF 20% 50V
C719 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C720 1-124-257-00 ELECT 2.2uF 20% 50V
C721 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C722 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C724 1-124-463-00 ELECT 0.1uF 20% 50V
C777 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C779 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C780 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C781 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C782 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< DIODE >
D700 6-501-579-01 DIODE MC2837
D701 6-501-579-01 DIODE MC2837
< IC >
IC700 8-759-278-58 IC NJM4558V-TE2
< JACK >
J700 1-822-757-11 JACK (LARGE TYPE) (MIC)
J702 1-794-702-11 JACK, HEADPHONE (PHONES)
< JUMPER RESISTOR >
JR701 1-216-864-11 SHORT CHIP 0
JR702 1-216-864-11 SHORT CHIP 0
JR703 1-216-296-11 SHORT CHIP 0
JR704 1-216-296-11 SHORT CHIP 0
JR705 1-216-296-11 SHORT CHIP 0
JR706 1-216-296-11 SHORT CHIP 0
JR707 1-216-295-91 SHORT CHIP 0
JR708 1-216-864-11 SHORT CHIP 0
JR709 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R700 1-216-821-11 METAL CHIP 1K 5% 1/10W
R701 1-216-845-11 METAL CHIP 100K 5% 1/10W
R702 1-216-833-11 METAL CHIP 10K 5% 1/10W
R704 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R705 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R706 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R711 1-216-833-11 METAL CHIP 10K 5% 1/10W
R712 1-216-836-11 METAL CHIP 18K 5% 1/10W
R714 1-216-849-11 METAL CHIP 220K 5% 1/10W
R715 1-216-809-11 METAL CHIP 100 5% 1/10W
R716 1-216-845-11 METAL CHIP 100K 5% 1/10W
R720 1-216-845-11 METAL CHIP 100K 5% 1/10W
R721 1-216-836-11 METAL CHIP 18K 5% 1/10W
R722 1-216-833-11 METAL CHIP 10K 5% 1/10W
R723 1-216-836-11 METAL CHIP 18K 5% 1/10W
R724 1-216-841-11 METAL CHIP 47K 5% 1/10W
R725 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VARIABLE RESISTOR >
RV700 1-227-452-11 RES, VAR, CARBON 50K (MIC LEVEL)
*************************************************************
POWER BOARD
*************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
(GTR55/GTR77)
< CAPACITOR >
C801 1-130-777-00 MYLAR 0.1uF 5% 100V
C802 1-130-777-00 MYLAR 0.1uF 5% 100V
C803 1-137-840-11 ELECT (BLOCK) 2200uF 20% 63V
(GTR33)
C803 1-137-842-11 ELECT (BLOCK) 2200uF 20% 80V
(GTR55/GTR77)
C804 1-137-840-11 ELECT (BLOCK) 2200uF 20% 63V
(GTR33)
C804 1-137-842-11 ELECT (BLOCK) 2200uF 20% 80V
(GTR55/GTR77)
C805 1-127-811-11 ELECT (BLOCK) 3300uF 20% 50V
(GTR77)
C805 1-137-839-11 ELECT (BLOCK) 2200uF 20% 50V
(GTR55)
C806 1-127-811-11 ELECT (BLOCK) 3300uF 20% 50V
(GTR77)
C806 1-137-839-11 ELECT (BLOCK) 2200uF 20% 50V
(GTR55)
C807 1-130-777-00 MYLAR 0.1uF 5% 100V
(GTR55/GTR77)
C808 1-130-777-00 MYLAR 0.1uF 5% 100V
(GTR55/GTR77)
C809 1-126-964-11 ELECT 10uF 20% 50V
C810 1-126-964-11 ELECT 10uF 20% 50V
C811 1-126-964-11 ELECT 10uF 20% 50V
C812 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C813 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C814 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C815 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C816 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C817 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C818 1-126-967-11 ELECT 47uF 20% 50V
C819 1-126-967-11 ELECT 47uF 20% 50V
C820 1-126-967-11 ELECT 47uF 20% 50V
C826 1-128-552-51 ELECT 47uF 20% 63V
(GTR33)
C826 1-128-562-11 ELECT 47uF 20% 100V
(GTR55/GTR77)
MAIN MIC POWER
