Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GTR33/GTR55/GTR77
70
0 R865 1-250-336-11 FUSIBLE 100 5% 1/2W
R866 1-202-926-11 METAL CHIP 36K 5% 1/10W
(GTR55/GTR77)
R866 1-216-840-11 METAL CHIP 39K 5% 1/10W
(GTR33)
R868 1-216-839-11 METAL CHIP 33K 5% 1/10W
R881 1-216-841-11 METAL CHIP 47K 5% 1/10W
R882 1-216-843-11 METAL CHIP 68K 5% 1/10W
(GTR33)
R882 1-216-844-11 METAL CHIP 82K 5% 1/10W
(GTR55/GTR77)
R883 1-216-821-11 METAL CHIP 1K 5% 1/10W
R884 1-216-841-11 METAL CHIP 47K 5% 1/10W
R885 1-216-842-11 METAL CHIP 56K 5% 1/10W
R887 1-216-864-11 SHORT CHIP 0
R889 1-216-834-11 METAL CHIP 12K 5% 1/10W
(GTR55/GTR77)
R889 1-216-839-11 METAL CHIP 33K 5% 1/10W
(GTR33)
R891 1-216-845-11 METAL CHIP 100K 5% 1/10W
R892 1-216-845-11 METAL CHIP 100K 5% 1/10W
R905 1-250-312-21 METAL CHIP 10 5% 1/2W
R906 1-250-312-21 METAL CHIP 10 5% 1/2W
R910 1-250-312-21 METAL CHIP 10 5% 1/2W
< RELAY >
RY800 1-755-653-11 RELAY
< THERMISTOR >
TH802 1-804-045-11 THERMISTOR
*************************************************************
TC BOARD (E4)
************
< CAPACITOR >
C501 1-104-658-91 ELECT 100uF 20% 10V
C502 1-104-658-91 ELECT 100uF 20% 10V
C503 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C504 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C506 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C509 1-127-804-91 CERAMIC CHIP 100PF 1% 50V
C510 1-127-804-91 CERAMIC CHIP 100PF 1% 50V
C511 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C512 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C513 1-126-160-11 ELECT 1uF 20% 50V
C514 1-126-160-11 ELECT 1uF 20% 50V
C515 1-126-786-11 ELECT 47uF 20% 16V
C516 1-126-947-11 ELECT 47uF 20% 35V
C517 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C519 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C520 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C521 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C522 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C523 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C524 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C525 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C526 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C527 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C528 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C529 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C530 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C531 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C532 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C533 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C534 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C535 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C536 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C537 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C538 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C539 1-115-156-11 CERAMIC CHIP 1uF 10V
C540 1-130-479-91 MYLAR 0.0047uF 5% 50V
C542 1-126-796-11 ELECT 22uF 20% 50V
C543 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C545 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C546 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C548 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C549 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
* CN501 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN502 1-784-731-11 CONNECTOR, FFC 9P
< IC >
IC501 8-759-100-96 IC uPC4558G2
IC502 8-759-100-96 IC uPC4558G2
< JUMPER RESISTOR >
JR501 1-216-864-11 SHORT CHIP 0
JR502 1-216-864-11 SHORT CHIP 0
JR503 1-216-864-11 SHORT CHIP 0
JR504 1-216-295-91 SHORT CHIP 0
JR505 1-216-295-91 SHORT CHIP 0
JR506 1-216-296-11 SHORT CHIP 0
JR507 1-216-296-11 SHORT CHIP 0
JR508 1-216-296-11 SHORT CHIP 0
JR509 1-216-296-11 SHORT CHIP 0
JR510 1-216-295-91 SHORT CHIP 0
JR511 1-216-296-11 SHORT CHIP 0
JR512 1-216-296-11 SHORT CHIP 0
JR513 1-216-296-11 SHORT CHIP 0
JR514 1-216-296-11 SHORT CHIP 0
JR515 1-216-296-11 SHORT CHIP 0
JR516 1-216-296-11 SHORT CHIP 0
JR517 1-216-296-11 SHORT CHIP 0
JR518 1-216-296-11 SHORT CHIP 0
< COIL >
L501 1-456-094-11 TRANSFORMER, BIAS OSCILLATION
< TRANSISTOR >
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q502 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R501 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R502 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R503 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R504 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R505 1-216-834-11 METAL CHIP 12K 5% 1/10W
POWER TC
