Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GTR33/GTR55/GTR77
72
C1012 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C1013 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
< CONNECTOR >
CN1000 1-819-866-11 CONNECTOR, USB (A) (REC/PLAY B)
CN1001 1-819-866-11 CONNECTOR, USB (A) (PLAY A)
< DIODE >
D1000 6-502-795-01 DI 1L0351B12C0MXT02
D1002 6-503-224-01 DI 1L0351V22F0MIT01
D1003 6-502-795-01 DI 1L0351B12C0MXT02
D1004 6-501-579-01 DIODE MC2837
D1005 6-501-579-01 DIODE MC2837
D1006 6-501-579-01 DIODE MC2837
D1007 6-501-579-01 DIODE MC2837
D1008 6-501-579-01 DIODE MC2837
D1009 6-501-579-01 DIODE MC2837
D1011 6-501-743-01 DIODE MAZ8068GMLS0
D1013 6-501-743-01 DIODE MAZ8068GMLS0
D1015 6-501-743-01 DIODE MAZ8068GMLS0
D1017 6-501-743-01 DIODE MAZ8068GMLS0
D1018 6-501-743-01 DIODE MAZ8068GMLS0
D1019 6-501-743-01 DIODE MAZ8068GMLS0
< JUMPER RESISTOR >
JR102 1-216-296-11 SHORT CHIP 0
JR103 1-216-296-11 SHORT CHIP 0
< RESISTOR >
R1001 1-216-817-11 METAL CHIP 470 5% 1/10W
R1002 1-216-817-11 METAL CHIP 470 5% 1/10W
R1004 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1005 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1008 1-216-817-11 METAL CHIP 470 5% 1/10W
R1009 1-216-817-11 METAL CHIP 470 5% 1/10W
*************************************************************
VOL BOARD
**********
< CAPACITOR >
C1301 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< RESISTOR >
R1302 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1303 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1304 1-216-837-11 METAL CHIP 22K 5% 1/10W
< SWITCH >
S1301 1-487-171-11 ROTARY ENCODER (MASTER VOLUME)
S1302 1-786-289-31 SWITCH, DETECTION (DETECTION SWITCH)
*************************************************************
MISCELLANEOUS
**************
59 1-797-575-11 DECK, MECHANICAL (E4)
103 1-828-311-51 WIRE (FLAT TYPE) (9 CORE)
104 1-836-973-11 WIRE (FLAT TYPE) (7 CORE)
105 1-828-975-11 WIRE (FLAT TYPE) (13 CORE)
155 1-838-059-11 FLEXIBLE FLAT CABLE (23 CORE)
156 1-828-964-11 WIRE (FLAT TYPE) (11 CORE) (GTR55/GTR77)
251 1-828-952-11 WIRE (FLAT TYPE) (9 CORE)
252 1-457-369-12 CORE, FERRITE
255 1-693-778-31 TUNER (FM/AM)
0 257 1-777-071-83 CORD, POWER (E2, E51, E4)
0 257 1-837-312-11 CORD, POWER-SUPPLY (AR)
0 257 1-837-344-11 CORD, POWER-SUPPLY (MX)
0 258 1-569-008-21 ADAPTOR, CONVERSION (E2, E51, E4)
401 1-840-387-31 MECHANICAL, CD
0 405 8-820-322-04 DEVICE, OPTICAL KHM-313CAB/C2NP)
(Including sled motor, spindle motor)
407 1-828-773-51 WIRE (FLAT TYPE) (24 CORE)
M101 1-787-344-21 FAN, DC
0 PT901 1-445-827-11 POWER TRANSFORMER (MAIN) (GTR33: MX)
0 PT901 1-445-828-11 POWER TRANSFORMER (MAIN) (GTR33: E4)
0 PT901 1-445-829-11 POWER TRANSFORMER (MAIN)
(GTR33: E2, E51, AR)
0 PT901 1-445-830-11 POWER TRANSFORMER (MAIN) (GTR77: MX)
0 PT901 1-445-831-11 POWER TRANSFORMER (MAIN) (GTR77: E4)
0 PT901 1-445-832-11 POWER TRANSFORMER (MAIN)
(GTR77: E2, E51, AR)
0 PT901 1-445-834-11 POWER TRANSFORMER (MAIN) (GTR55: MX)
0 PT901 1-445-835-11 POWER TRANSFORMER (MAIN)
(GTR55: E2, E51, AR)
0 PT901 1-445-836-11 POWER TRANSFORMER (MAIN) (GTR55: E4)
*************************************************************
USB VOL
