Sony HCD-GTR88 - Front Panel Section

57
HCD-GTR88
7-5. FRONT PANEL SECTION
201 2-895-507-01 KNOB (MIC)
202 X-2541-955-1 FRONT PANEL ASSY (GVX-COM) (EXCEPT E4)
202 X-2546-463-1 FRONT PANEL ASSY (GVX-E4) (E4)
203 4-225-252-01 CUSHION (FOOT)
204 3-087-053-01 +BVTP 2.6 (3CR)
205 4-164-351-01 WINDOW (FL)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark
#2
not
supplied
not
supplied
not supplied
(MIC board)
not supplied
not supplied
(USB board)
not supplied
201
202
205
203
204
204
204
204
