Sony HCD-HDX285 User Manual

HCD-HDX285/HDX287WC/HDX585/HDX587WC/HDX589W/HDX685/HDX686W
HCD-HDX285/HDX287WC/HDX585/HDX587WC/HDX589W/HDX685/HDX686W
5959
• Waveforms
– MAIN Board –

IC3051 
2 V/DIV, 10 ns/DIV
20.4 ns
3.2 Vp-p

IC3010 SL (XFSOIN)
2 V/DIV, 10 ns/DIV
20.4 ns
3.3 Vp-p

IC3010 RG (XFSOOUT)
2 V/DIV, 10 ns/DIV
20.4 ns
3.5 Vp-p

IC503 RE (Xout)
2 V/DIV, 100 ns/DIV
200 ns
3.4 Vp-p

IC304 XB (XOUT(O))
2 V/DIV, 20 ns/DIV
40.8 ns
3.9 Vp-p
IC1101 R (DVDRFIP)
(DVD play mode)
420 mVp-p

200 mV/DIV, 100 ns/DIV

IC1101 [Y (R/Cr/Pr)
(Color bar)
H
0.8 Vp-p
RB
H
1 Vp-p
RT
IC1101 YD (XTALO)
1 V/DIV, 1 ms/DIV
800 ns
1.4 Vp-p
500 mV/DIV, 50 μs/DIV

IC1101 [D (B/Cb/Pb)
(Color bar)
H
0.8 Vp-p
500 mV/DIV, 50 μs/DIV
500 mV/DIV, 50 μs/DIV
R
IC1101 [ (C)
(Color bar)
IC1101 [[ (Y)
(Color bar)
H
0.9 Vp-p
500 mV/DIV, 20 μs/DIV

IC1101 [C (Y/G)
(Color bar)
H
1 Vp-p
500 mV/DIV, 50 μs/DIV
XB
IC4002  (CIN)
(Color bar)
500 mV/DIV, 20 μs/DIV
H
0.9 Vp-p
XT
IC4002  (YIN)
(Color bar)
500 mV/DIV, 50 μs/DIV
H
1 Vp-p
XE
IC4002 RB (CYIN)
(Color bar)
500 mV/DIV, 50 μs/DIV
H
1 Vp-p
XG
IC4002 RE (CbIN)
(Color bar)
200 mV/DIV, 20 μs/DIV
H
0.7 Vp-p
XH
IC4002 RH (CrIN)
(Color bar)
200 mV/DIV, 20 μs/DIV
H
0.7 Vp-p
XI
IC4002 RL (CrOUTa)
(Color bar)
500 mV/DIV, 20 μs/DIV
H
1.5 Vp-p
XK
IC4002 XB (CbOUTa)
(Color bar)
500 mV/DIV, 20 μs/DIV
H
1.5 Vp-p
XL
IC4002 XG (CYOUTa)
(Color bar)
1 V/DIV, 50 μs/DIV
H
2.1 Vp-p
XM
IC4002 F (VOUTa)
(Color bar)
1 V/DIV, 20 μs/DIV
H
2.5 Vp-p
81 ns
3.7 Vp-p
FB
IC802 
2 V/DIV, 50 ns/DIV
SB
Q5000 (Collector)
10 V/DIV, 5 μs/DIV
6.9 μs
15.6 Vp-p
– I/O Board – – S-AIR INCLUDE Board –
– FL-JACK Board –
