Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-HDX285/HDX287WC/HDX585/HDX587WC/HDX589W/HDX685/HDX686W
8989
J5001 1-822-262-11 JACK (PHONES)
< JUMPER RESISTOR >
JR5005 1-216-296-11 SHORT CHIP 0
JR5006 1-216-864-11 SHORT CHIP 0
JR5014 1-216-864-11 SHORT CHIP 0
JR5015 1-216-864-11 SHORT CHIP 0
JR5019 1-216-864-11 SHORT CHIP 0
< COIL >
L5000 1-410-671-31 INDUCTOR 47uH
L5001 1-410-671-31 INDUCTOR 47uH
L5002 1-410-671-31 INDUCTOR 47uH
< FLUORESCENT INDICATOR TUBE >
ND5000 1-519-988-21 INDICATOR TUBE, FLUORESCENT
< TRANSISTOR >
Q5000 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q5003 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q5004 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q5005 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q5006 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q5007 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q5008 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q5009 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q5010 8-729-038-11 TRANSISTOR RT1P140C-TP-1
Q5011 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q5012 8-729-038-28 TRANSISTOR RT1N441C-TP-1
< RESISTOR >
R5000 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R5001 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5003 1-216-813-11 METAL CHIP 220 5% 1/10W
R5004 1-216-813-11 METAL CHIP 220 5% 1/10W
R5005 1-216-813-11 METAL CHIP 220 5% 1/10W
R5006 1-216-839-11 METAL CHIP 33K 5% 1/10W
R5007 1-216-813-11 METAL CHIP 220 5% 1/10W
R5008 1-216-805-11 METAL CHIP 47 5% 1/10W
R5009 1-216-805-11 METAL CHIP 47 5% 1/10W
R5010 1-216-809-11 METAL CHIP 100 5% 1/10W
R5011 1-216-809-11 METAL CHIP 100 5% 1/10W
R5012 1-216-809-11 METAL CHIP 100 5% 1/10W
R5013 1-216-844-11 METAL CHIP 82K 5% 1/10W
R5016 1-216-810-11 METAL CHIP 120 5% 1/10W
R5017 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5018 1-216-805-11 METAL CHIP 47 5% 1/10W
R5019 1-216-835-11 METAL CHIP 15K 5% 1/10W
R5020 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5021 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5022 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5023 1-216-834-11 METAL CHIP 12K 5% 1/10W
R5024 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5025 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5026 1-216-801-11 METAL CHIP 22 5% 1/10W
R5027 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5028 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5029 1-216-819-11 METAL CHIP 680 5% 1/10W
R5030 1-216-811-11 METAL CHIP 150 5% 1/10W
R5031 1-216-835-11 METAL CHIP 15K 5% 1/10W
I/O
R5032 1-216-809-11 METAL CHIP 100 5% 1/10W
R5033 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5034 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5035 1-216-864-11 SHORT CHIP 0
R5036 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5037 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5038 1-216-837-11 METAL CHIP 22K 5% 1/10W
R5039 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5041 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W
R5043 1-216-817-11 METAL CHIP 470 5% 1/10W
R5044 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5045 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5047 1-216-817-11 METAL CHIP 470 5% 1/10W
R5048 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5049 1-216-837-11 METAL CHIP 22K 5% 1/10W
R5050 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5051 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5052 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5053 1-216-864-11 SHORT CHIP 0
R5054 1-216-857-11 METAL CHIP 1M 5% 1/10W
R5055 1-216-837-11 METAL CHIP 22K 5% 1/10W
R5056 1-216-864-11 SHORT CHIP 0
R5083 1-216-813-11 METAL CHIP 220 5% 1/10W
R5084 1-216-813-11 METAL CHIP 220 5% 1/10W
R5085 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5086 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5087 1-216-837-11 METAL CHIP 22K 5% 1/10W
R5088 1-216-841-11 METAL CHIP 47K 5% 1/10W
R5090 1-216-809-11 METAL CHIP 100 5% 1/10W
(SUFFIX-12)
R5091 1-216-809-11 METAL CHIP 100 5% 1/10W
(SUFFIX-12)
< SWITCH >
S5000 1-762-875-21 SWITCH, KEYBOARD (DMPORT BOOSTER)
< TRANSFORMER >
T5000 1-443-645-11 TRANSFORMER, DC CONVERTER
************************************************************
A-1602-537-A I/O BOARD, COMPLETE
*******************
< CAPACITOR >
C4028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4030 1-126-933-11 ELECT 100uF 20% 16V
C4031 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4033 1-126-933-11 ELECT 100uF 20% 16V
C4034 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4036 1-126-916-11 ELECT 1000uF 20% 6.3V
C4037 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4039 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C4040 1-126-916-11 ELECT 1000uF 20% 6.3V
C4041 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4042 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4043 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C4044 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4045 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4046 1-126-925-91 ELECT 470uF 20% 10V
C4047 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
FL-JACK
Note: Refer to the Servicing Notes “FL-JACK AND P-SW BOARDS DISCRIMINATION”
(page 5) for how to distinguish Suffi x-11 and Suffi x-12.
