HCD-HX3/HX5/HX7
7-2.
CHASSIS (T
OP) SECTION
Ref. No.
Part No.
Description
Remark
Ref. No.
Part No.
Description
Remark
51
3-198-753-01
FOOT (FEL
T)
52
2-895-152-01
KNOB (VOL)
#1
7-685-646-79
SCREW +BVTP 3X8 TYPE2 IT-3
#2
7-685-871-01
SCREW +BVTT 3X6 (S)
#2
#2
#2
#2
#1
not supplied
main section
51
52
51
panel ke
y section
64
66
