• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
SET
3-2. PANEL (TOP)
(Page 10)
3-3. FRONT PANEL BLOCK
(Page 10)
3-7. LOADING MECHANISM
BLOCK
(Page 12)
3-8. BASE UNIT
(Page 13)
3-9. BELT
(Page 13)
3-10. OP BASE ASSY
(KSM-213D)
(Page 14)
3-6. SWITCHING POWER BOARD/
SUB POWER BOARD
(Page 12)
3-4. MAIN BOARD
(HX3/HX5)
(Page 11)
(HX3/HX5)
3-5. MAIN BOARD/XM BOARD
(HX7)
(Page 11)
(HX7)
