Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
73
HCD-HX3/HX5/HX7
C757 1-126-964-11 ELECT 10uF 20% 50V
(HX3/HX7)
C757 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(HX5)
C758 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C759 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(HX5)
C760 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(HX3/HX7)
C761 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C762 1-100-717-91 CERAMIC CHIP 1uF 16V
(HX5)
C762 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(HX3/HX7)
C763 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C764 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(HX3/HX7)
C764 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
(HX5)
C765 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(HX3/HX7)
C765 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
(HX5)
C766 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(HX3/HX7)
C766 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
(HX5)
C767 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(HX3/HX7)
C767 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
(HX5)
C768 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C769 1-100-924-21 ELECT 2200uF 20% 35V
(HX5)
C769 1-137-806-21 ELECT 1800uF 20% 35V
(HX3/HX7)
C770 1-137-198-11 FILM 1uF 5% 50V
C772 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C773 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C774 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C775 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C777 1-137-198-11 FILM 1uF 5% 50V
C778 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C779 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C780 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C781 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(HX5)
C781 1-126-964-11 ELECT 10uF 20% 50V
(HX3/HX7)
C782 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(HX5)
C783 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C784 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C785 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C786 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C787 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C788 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C790 1-126-933-11 ELECT 100uF 20% 16V
(HX3/HX7)
C791 1-136-497-81 FILM 0.1uF 5% 50V
C793 1-126-964-11 ELECT 10uF 20% 50V
(HX5)
C794 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C795 1-126-964-11 ELECT 10uF 20% 50V
(HX5)
C796 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C797 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C798 1-126-964-11 ELECT 10uF 20% 50V
C799 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C804 1-163-205-00 CERAMIC CHIP 0.001uF 10% 50V
C806 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C831 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C832 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C844 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C845 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C846 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C847 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN700 1-784-780-11 CONNECTOR, FFC 19P
< DIODE >
D701 6-501-193-01 DIODE 1SS355WTE-17
D702 6-501-193-01 DIODE 1SS355WTE-17 (HX3/HX7)
D705 6-500-260-01 DIODE P6SMB39AT3 (HX5)
D706 6-500-260-01 DIODE P6SMB39AT3 (HX5)
D713 6-501-159-01 DIODE UDZW-TE17-2.4B (HX5)
D751 6-501-193-01 DIODE 1SS355WTE-17 (HX5)
D755 6-500-260-01 DIODE P6SMB39AT3 (HX5)
D756 6-500-260-01 DIODE P6SMB39AT3 (HX5)
< EARTH TERMINAL >
EP701 1-537-771-21 TERMINAL BOARD, GROUND
EP702 1-537-771-21 TERMINAL BOARD, GROUND
EP703 1-537-771-21 TERMINAL BOARD, GROUND
< IC >
IC701 6-707-608-01 IC PCM1803DBR
IC702 6-708-637-01 IC NJM2871BF33-TE2
IC703 6-701-261-01 IC MC74VHC74DTR2
IC704 6-707-956-01 IC NJM2871BF18-TE2
IC705 6-705-979-01 IC CXD9788AR
IC707 6-704-802-01 IC CXD9774M (HX5)
IC707 6-710-134-01 IC CXD9845AM (HX3/HX7)
IC708 6-704-802-01 IC CXD9774M (HX5)
IC709 6-701-189-01 IC MC74VHC1GU04DFT1
< COIL >
L701 1-469-967-21 INDUCTOR 10uH
L702 1-469-967-21 INDUCTOR 10uH
L703 1-469-967-21 INDUCTOR 10uH
L704 1-469-967-21 INDUCTOR 10uH
L705 1-412-939-11 INDUCTOR 1uH
L708 1-456-813-11 COIL, AIR-CORE (HX5)
L709 1-456-813-11 COIL, AIR-CORE (HX5)
L710 1-456-680-11 CHOKE, COIL 10uH
L711 1-456-680-11 CHOKE, COIL 10uH
L758 1-456-813-11 COIL, AIR-CORE (HX5)
AMP
