Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
89
HCD-HX3/HX5/HX7
R005 1-216-845-11 METAL CHIP 100K 5% 1/10W
R006 1-216-845-11 METAL CHIP 100K 5% 1/10W
R007 1-216-833-11 METAL CHIP 10K 5% 1/10W
R008 1-216-821-11 METAL CHIP 1K 5% 1/10W
R009 1-216-821-11 METAL CHIP 1K 5% 1/10W
R010 1-216-809-11 METAL CHIP 100 5% 1/10W
R011 1-216-809-11 METAL CHIP 100 5% 1/10W
R012 1-216-845-11 METAL CHIP 100K 5% 1/10W
R014 1-216-809-11 METAL CHIP 100 5% 1/10W
R015 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R016 1-216-817-11 METAL CHIP 470 5% 1/10W
R017 1-216-809-11 METAL CHIP 100 5% 1/10W
R018 1-216-809-11 METAL CHIP 100 5% 1/10W
R019 1-216-809-11 METAL CHIP 100 5% 1/10W
R020 1-216-837-11 METAL CHIP 22K 5% 1/10W
R021 1-216-809-11 METAL CHIP 100 5% 1/10W
R022 1-216-809-11 METAL CHIP 100 5% 1/10W
R023 1-216-809-11 METAL CHIP 100 5% 1/10W
R024 1-216-809-11 METAL CHIP 100 5% 1/10W
R025 1-216-809-11 METAL CHIP 100 5% 1/10W
R026 1-216-809-11 METAL CHIP 100 5% 1/10W
R031 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R032 1-216-841-11 METAL CHIP 47K 5% 1/10W
R033 1-216-841-11 METAL CHIP 47K 5% 1/10W
R034 1-216-841-11 METAL CHIP 47K 5% 1/10W
R035 1-216-841-11 METAL CHIP 47K 5% 1/10W
R036 1-216-833-11 METAL CHIP 10K 5% 1/10W
R037 1-216-833-11 METAL CHIP 10K 5% 1/10W
R051 1-216-841-11 METAL CHIP 47K 5% 1/10W
R052 1-216-841-11 METAL CHIP 47K 5% 1/10W
R055 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R056 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R057 1-216-821-11 METAL CHIP 1K 5% 1/10W
R065 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R066 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R067 1-216-821-11 METAL CHIP 1K 5% 1/10W
< VIBRATOR >
X001 1-760-841-11 VIBRATOR, CRYSTAL (45.158MHz)
************************************************************
XM REGULATOR BOARD (HX7)
********************
< CAPACITOR >
C359 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C360 1-126-923-91 ELECT 220uF 20% 10V
< DIODE >
D215 8-719-085-36 DIODE 11EQS04-TB5
< IC >
0 IC309 8-759-646-52 IC KIA7805API
************************************************************
XM REGULATORXM
MISCELLANEOUS
**************
102 1-832-589-21 CABLE, FLEXIBLE FLAT (15 CORE) (HX5/HX7)
108 1-834-115-11 CABLE, COAXIAL (WITH U.F.L CONNECTOR
(HX5/HX7)
158 1-831-756-21 CABLE, FLEXIBLE FLAT (5 CORE)
159 1-831-797-21 CABLE, FLEXIBLE FLAT (17 CORE)
202 1-833-048-21 CABLE, FLEXIBLE FLAT (15 CORE) (HX7)
208 1-832-535-21 CABLE, FLEXIBLE FLAT (5 CORE)
251 1-832-608-21 CABLE, FLEXIBLE FLAT (19 CORE) (HX3/HX5)
253 1-832-815-21 CABLE, FLEXIBLE FLAT (9 CORE)
(HX3: CND/HX5: CND, AUS, KR/HX7)
253 1-832-825-21 CABLE, FLEXIBLE FLAT (11 CORE)
(HX3: AEP/HX5: AEP, UK)
254 1-693-733-21 TUNER (FM/AM) (HX3: CND/HX5: CND/HX7)
254 1-693-734-21 TUNER (FM/AM) (HX5: AUS)
254 1-693-735-11 TUNER (FM/AM) (HX5: KR)
254 1-693-736-11 TUNER (FM/AM) (HX3: AEP/HX5: AEP, UK)
255 1-457-368-11 CORE, FERRITE (HX5)
0 256 1-769-079-41 CORD, POWER (HX5: KR)
0 256 1-769-744-81 CORD, POWER (HX5: UK)
0 256 1-775-790-71 CORD, POWER (HX5: AUS)
0 256 1-830-188-11 CORD, POWER (HX3: AEP/HX5: AEP)
0 256 1-830-190-11 CORD, POWER (HX3: CND/HX5: CND/HX7)
259 1-832-865-21 CABLE, FLEXIBLE FLAT (19 CORE)
260 1-400-932-11 FILTER, CLAMP
301 A-1242-967-A LOADING (BK) ASSY
306 1-832-615-21 CABLE, FLEXIBLE FLAT (21 CORE) (HX7)
306 1-832-635-21 CABLE, FLEXIBLE FLAT (25 CORE) (HX3/HX5)
0 351 A-4735-357-A BASE ASSY, OP (KSM-213D)
352 1-832-404-21 CABLE, FLEXIBLE FLAT (16 CORE)
S201 1-771-853-11 SWITCH, DETECTION (LIMIT)
************************************************************
ACCESSORIES
************
0 1-770-019-61 ADAPTOR, CONVERSION PLUG (HX5: UK)
Note: If wire (flat type) is replaced, install it after
bending it in the same form as that before
replacement.
