Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
89
HCD-M10
R871 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R872 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R873 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
< VIBRATOR >
X720 1-579-175-11 VIBRATOR, CERAMIC (10MHz)
******************************************************
A-4728-616-A PANEL BOARD, COMPLETE (AEP,UK)
A-4728-622-A PANEL BOARD, COMPLETE (EXCEPT AEP,UK)
********************
< CAPACITOR >
C841 1-126-963-11 ELECT 4.7uF 20% 50V
C842 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C874 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C875 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C876 1-104-665-11 ELECT 100uF 20% 10V
< CONNECTOR >
CN501 1-784-786-11 CONNECTOR, FFC 25P
CN502 1-785-318-11 PIN, CONNECTOR (STRAIGHT) 6P
< DIODE >
D805 8-719-058-04 DIODE SEL5223S-TP15
D806 8-719-057-97 DIODE SEL5923A-TP15
D807 8-719-057-97 DIODE SEL5923A-TP15
D808 8-719-057-97 DIODE SEL5923A-TP15
D809 8-719-057-97 DIODE SEL5923A-TP15
D812 8-719-057-97 DIODE SEL5923A-TP15
D813 8-719-057-97 DIODE SEL5923A-TP15
D814 8-719-057-97 DIODE SEL5923A-TP15
< FERRITE BEADS >
FB811 1-216-295-00 SHORT 0
FB812 1-216-295-00 SHORT 0
FB813 1-216-295-00 SHORT 0
< IC >
IC801 8-759-827-70 IC NJL64H400A-1
< TRANSISTOR >
Q803 8-729-421-22 TRANSISTOR UN2211
Q804 8-729-421-22 TRANSISTOR UN2211
Q805 8-729-421-22 TRANSISTOR UN2211
Q806 8-729-421-22 TRANSISTOR UN2211
Q807 8-729-421-22 TRANSISTOR UN2211
Q808 8-729-421-22 TRANSISTOR UN2211
Q809 8-729-421-22 TRANSISTOR UN2211
Q810 8-729-421-22 TRANSISTOR UN2211
Q811 8-729-421-22 TRANSISTOR UN2211
< RESISTOR >
R800 1-216-073-00 RES-CHIP 10K 5% 1/10W
R801 1-216-049-11 RES-CHIP 1K 5% 1/10W
R802 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R803 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R804 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R805 1-216-049-11 RES-CHIP 1K 5% 1/10W
R806 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R807 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R808 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R809 1-216-073-00 RES-CHIP 10K 5% 1/10W
R810 1-216-081-00 METAL CHIP 22K 5% 1/10W
R831 1-216-073-00 RES-CHIP 10K 5% 1/10W
R833 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R834 1-216-037-00 METAL CHIP 330 5% 1/10W
R836 1-216-025-11 RES-CHIP 100 5% 1/10W
R837 1-216-025-11 RES-CHIP 100 5% 1/10W
R838 1-216-025-11 RES-CHIP 100 5% 1/10W
R839 1-216-025-11 RES-CHIP 100 5% 1/10W
R840 1-216-025-11 RES-CHIP 100 5% 1/10W
R841 1-216-025-11 RES-CHIP 100 5% 1/10W
R842 1-216-025-11 RES-CHIP 100 5% 1/10W
R843 1-216-025-11 RES-CHIP 100 5% 1/10W
R844 1-216-025-11 RES-CHIP 100 5% 1/10W
R845 1-216-025-11 RES-CHIP 100 5% 1/10W
R874 1-216-025-11 RES-CHIP 100 5% 1/10W
R875 1-216-025-11 RES-CHIP 100 5% 1/10W
R876 1-216-025-11 RES-CHIP 100 5% 1/10W
R877 1-216-025-11 RES-CHIP 100 5% 1/10W
R882 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R883 1-216-037-00 METAL CHIP 330 5% 1/10W
R884 1-216-037-00 METAL CHIP 330 5% 1/10W
R885 1-216-037-00 METAL CHIP 330 5% 1/10W
R886 1-216-037-00 METAL CHIP 330 5% 1/10W
R887 1-216-037-00 METAL CHIP 330 5% 1/10W
< SWITCH >
S809 1-762-875-21 SWITCH, KEYBOARD (M L +)
S810 1-762-875-21 SWITCH, KEYBOARD (– lm )
S811 1-762-875-21 SWITCH, KEYBOARD (x )
S812 1-762-875-21 SWITCH, KEYBOARD (Z MD)
S813 1-762-875-21 SWITCH, KEYBOARD (Z CD)
S817 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S818 1-762-875-21 SWITCH, KEYBOARD (BAND TUNER)
S819 1-762-875-21 SWITCH, KEYBOARD (TAPE bB)
S820 1-762-875-21 SWITCH, KEYBOARD (7 CD)
S821 1-762-875-21 SWITCH, KEYBOARD (MD 7)
S822 1-762-875-21 SWITCH, KEYBOARD (VOLUME +)
S823 1-762-875-21 SWITCH, KEYBOARD (VOLUME –)
S833 1-762-875-21 SWITCH, KEYBOARD (I/1)
*****************************************************
A-4727-747-A POWER BOARD, COMPLETE (AEP,UK)
A-4728-620-A POWER BOARD, COMPLETE (EXCEPT AEP,UK)
*********************
1-533-293-11 FUSE HOLDER
< CAPACITOR >
C901 1-128-548-11 ELECT 4700uF 20% 25V
C903 1-136-165-00 FILM 0.1uF 5% 50V
C904 1-136-165-00 FILM 0.1uF 5% 50V
C905 1-135-933-11 ELECT 22000uF 20% 16V
0 C918 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C919 1-113-925-11 CERAMIC 0.01uF 20% 250V
PANEL
POWER
MD DIGITAL
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
To Next Page
