HCD-M10
A-4727-748-A AMP BOARD, COMPLETE (AEP,UK)
A-4728-621-A AMP BOARD, COMPLETE (EXCEPT AEP,UK)
******************
< CAPACITOR >
C908 1-126-963-11 ELECT 4.7uF 20% 50V
C909 1-126-942-61 ELECT 1000uF 20% 25V
C910 1-162-294-31 CERAMIC 0.001uF 10% 50V
C911 1-126-957-11 ELECT 0.22uF 20% 50V
C912 1-127-888-21 CERAMIC 0.1uF 10% 50V
C913 1-127-888-21 CERAMIC 0.1uF 10% 50V
C914 1-127-888-21 CERAMIC 0.1uF 10% 50V
C915 1-127-888-21 CERAMIC 0.1uF 10% 50V
C916 1-136-169-00 FILM 0.22uF 5% 50V
C917 1-136-169-00 FILM 0.22uF 5% 50V
C920 1-162-286-21 CERAMIC 220PF 10% 50V
C921 1-126-957-11 ELECT 0.22uF 20% 50V
C922 1-127-888-21 CERAMIC 0.1uF 10% 50V
C923 1-127-888-21 CERAMIC 0.1uF 10% 50V
C924 1-127-888-21 CERAMIC 0.1uF 10% 50V
C925 1-127-888-21 CERAMIC 0.1uF 10% 50V
C926 1-136-169-00 FILM 0.22uF 5% 50V
C927 1-136-169-00 FILM 0.22uF 5% 50V
C930 1-162-286-21 CERAMIC 220PF 10% 50V
C950 1-126-947-11 ELECT 47uF 20% 25V
C951 1-104-665-11 ELECT 100uF 20% 25V
C952 1-126-964-11 ELECT 10uF 20% 50V
C953 1-104-665-11 ELECT 100uF 20% 25V
C954 1-126-964-11 ELECT 10uF 20% 50V
C955 1-126-933-11 ELECT 100uF 20% 16V
C956 1-126-964-11 ELECT 10uF 20% 50V
C957 1-126-933-11 ELECT 100uF 20% 16V
C958 1-126-964-11 ELECT 10uF 20% 50V
C959 1-126-933-11 ELECT 100uF 20% 16V
C960 1-126-964-11 ELECT 10uF 20% 50V
C961 1-127-876-21 CERAMIC 0.01uF 10% 50V
C962 1-127-876-21 CERAMIC 0.01uF 10% 50V
C963 1-127-876-21 CERAMIC 0.01uF 10% 50V
< CONNECTOR >
* CN901 1-770-732-11 CONNECTOR, BOARD TO BOARD 15P
CN902 1-784-784-11 CONNECTOR, FFC 23P
< DIODE >
D903 8-719-935-70 DIODE HZS11B2LTD
< IC >
IC901 6-702-093-01 IC LA4663N
IC902 8-759-231-58 IC TA7812S
IC903 8-759-231-58 IC TA7812S
IC904 8-759-071-48 IC TA7807S
IC905 8-759-158-62 IC TA78057S
IC906 8-759-231-53 IC TA7805S
< COIL >
L911 1-422-009-13 COIL, AIR-CORE
L912 1-422-009-13 COIL, AIR-CORE
L921 1-422-009-13 COIL, AIR-CORE
L922 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q901 8-729-900-80 TRANSISTOR DTC114ES
Q902 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R902 1-249-433-11 CARBON 22K 5% 1/4W
R903 1-249-429-11 CARBON 10K 5% 1/4W
R911 1-249-433-11 CARBON 22K 5% 1/4W
R912 1-249-385-11 CARBON 2.2 5% 1/6W F
R913 1-249-385-11 CARBON 2.2 5% 1/6W F
R914 1-260-076-11 CARBON 10 5% 1/2W
R915 1-260-076-11 CARBON 10 5% 1/2W
R917 1-260-076-11 CARBON 10 5% 1/2W
R921 1-249-433-11 CARBON 22K 5% 1/4W
R922 1-249-385-11 CARBON 2.2 5% 1/6W F
R923 1-249-385-11 CARBON 2.2 5% 1/6W F
R924 1-260-076-11 CARBON 10 5% 1/2W
R925 1-260-076-11 CARBON 10 5% 1/2W
R927 1-260-076-11 CARBON 10 5% 1/2W
R951 1-249-433-11 CARBON 22K 5% 1/4W
< RELAY >
RY991 1-755-276-11 RELAY, POWER
AMP
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “∗” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• CAPACITORS:
uF: µF
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
HK : Hong Kong model
SP : Singapore model
KR : Korea model
AUS: Australian model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
