Sony HCD-M10 - Page 79

79
HCD-M10
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
7-8. CD MECHANISM DECK-2 (BU-K4BD43)
557
557
557
557
556
556
556
556
558
554
555
553
553
553
553
552
551
#8
551 4-229-358-01 SHAFT (BU21)
552 4-231-780-01 HOLDER (213D)
553 4-229-004-01 SPRING, COMPRESSION
554 A-4728-686-A CD BOARD, COMPLETE
555 1-823-145-11 WIRE, PARALLEL (FFC) (16 CORE)
556 4-229-005-21 INSULATOR
557 4-985-672-01 SCREW (+PTPWHM2.6), FLOATING
0 558 A-4735-357-A DEVICE,OPTICAL KSM213DHAP/Z-NP
#8 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
