Sony HCD-M10 - Printed Wiring Board - CD Board

HCD-M10
4646
6-3. PRINTED WIRING BOARD – CD BOARD –
• See page 41 for Circuit Boards Location.
IC101
IC103
IC702
A
MAIN
BOARD
(Page 53)
TP
(DVC1.65V)
TP
(RFAC)
TP
(XPCK)
S101
(LIMIT IN)
TP
(TE)
40 21
20
214
4160
61 80
13
13
13
13
Ref. No. Location
D101 C-1
IC101 C-6
IC103 C-5
IC702 B-5
Q101 C-5
Q102 B-5
Q103 C-1
• Semiconductor
Location
