Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
83
HCD-M10
CD
< DIODE >
D815 8-719-079-49 DIODE NSSW450-BRS-TVR
D816 8-719-079-49 DIODE NSSW450-BRS-TVR
< RESISTOR >
R891 1-216-025-11 RES-CHIP 100 5% 1/10W
R892 1-216-025-11 RES-CHIP 100 5% 1/10W
******************************************************
A-4728-686-A CD BOARD, COMPLETE
*****************
< CAPACITOR >
C101 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C103 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C104 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C107 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C108 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C109 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C111 1-126-204-11 ELECT CHIP 47uF 20% 16V
C112 1-126-204-11 ELECT CHIP 47uF 20% 16V
C113 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-126-204-11 ELECT CHIP 47uF 20% 16V
C117 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C118 1-115-156-11 CERAMIC CHIP 1uF 10V
C119 1-115-156-11 CERAMIC CHIP 1uF 10V
C120 1-126-204-11 ELECT CHIP 47uF 20% 16V
C121 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C151 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C162 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C201 1-126-204-11 ELECT CHIP 47uF 20% 16V
C202 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C203 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C204 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C205 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C209 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C211 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C212 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C213 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C215 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C216 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C217 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C221 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C222 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C224 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C227 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C228 1-115-156-11 CERAMIC CHIP 1uF 10V
C229 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C230 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C231 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C234 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C235 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C236 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C237 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C238 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C239 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C240 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C241 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C242 1-126-204-11 ELECT CHIP 47uF 20% 16V
C243 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C244 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C245 1-126-204-11 ELECT CHIP 47uF 20% 16V
C247 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C248 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C249 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN101 1-784-873-21 CONNECTOR,FFC(LIF(NON-ZIF))22P
CN102 1-794-424-11 CONNECTOR, FCC/FPC 16P
< DIODE >
D101 8-719-056-77 DIODE UDZ-TE-17-3.9B
< FERRITE BEADS >
FB101 1-500-445-21 FERRITE 0UH
< IC >
IC101 8-752-408-73 IC CXD3068Q
IC103 8-752-089-74 IC CXA2581N-T4
IC702 8-759-640-22 IC BA5982FM
< COIL >
L107 1-500-445-21 FERRITE 0uH
< TRANSISTOR >
Q101 8-729-049-31 TRANSISTOR 2SB710A-RTX
Q102 8-759-068-54 TRANSISTOR KRA102S
Q103 8-729-920-85 TRANSISTOR 2SD1664-T100-QR
< RESISTOR >
R102 1-216-835-11 METAL CHIP 15K 5% 1/16W
R103 1-216-845-11 METAL CHIP 100K 5% 1/16W
R104 1-216-835-11 METAL CHIP 15K 5% 1/16W
R105 1-216-821-11 METAL CHIP 1K 5% 1/16W
R109 1-216-846-11 METAL CHIP 120K 5% 1/16W
R111 1-216-846-11 METAL CHIP 120K 5% 1/16W
R113 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R114 1-218-745-11 RES-CHIP 160K 5% 1/10W
R118 1-216-833-11 METAL CHIP 10K 5% 1/16W
R120 1-216-846-11 METAL CHIP 120K 5% 1/16W
R122 1-216-845-11 METAL CHIP 100K 5% 1/16W
R123 1-216-797-11 METAL CHIP 10 5% 1/16W
R124 1-216-798-11 RES-CHIP 12 5% 1/10W
R125 1-216-836-11 METAL CHIP 18K 5% 1/16W
R126 1-216-836-11 METAL CHIP 18K 5% 1/16W
R127 1-216-845-11 METAL CHIP 100K 5% 1/16W
R151 1-216-833-11 METAL CHIP 10K 5% 1/16W
R152 1-216-841-11 METAL CHIP 47K 5% 1/16W
R201 1-216-839-11 METAL CHIP 33K 5% 1/16W
R202 1-216-833-11 METAL CHIP 10K 5% 1/16W
R203 1-216-845-11 METAL CHIP 100K 5% 1/16W
R204 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
BL (WHITE)
