Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
84
HCD-M10
R205 1-216-821-11 METAL CHIP 1K 5% 1/16W
R206 1-216-833-11 METAL CHIP 10K 5% 1/16W
R207 1-216-857-11 METAL CHIP 1M 5% 1/16W
R212 1-216-813-11 METAL CHIP 220 5% 1/16W
R213 1-216-864-11 METAL CHIP 0 5% 1/16W
R214 1-216-864-11 METAL CHIP 0 5% 1/16W
R215 1-216-864-11 METAL CHIP 0 5% 1/16W
R216 1-216-813-11 METAL CHIP 220 5% 1/16W
R217 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R218 1-216-821-11 METAL CHIP 1K 5% 1/16W
R219 1-216-821-11 METAL CHIP 1K 5% 1/16W
R221 1-216-813-11 METAL CHIP 220 5% 1/16W
R226 1-216-809-11 METAL CHIP 100 5% 1/16W
R227 1-216-845-11 METAL CHIP 100K 5% 1/16W
R228 1-216-853-11 METAL CHIP 470K 5% 1/16W
R229 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R230 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R240 1-216-837-11 METAL CHIP 22K 5% 1/16W
R241 1-216-837-11 METAL CHIP 22K 5% 1/16W
R242 1-216-837-11 METAL CHIP 22K 5% 1/16W
R243 1-216-837-11 METAL CHIP 22K 5% 1/16W
R244 1-218-344-11 RES-CHIP 7.5K 5% 1/10W
R245 1-218-344-11 RES-CHIP 7.5K 5% 1/10W
R246 1-218-344-11 RES-CHIP 7.5K 5% 1/10W
R247 1-218-344-11 RES-CHIP 7.5K 5% 1/10W
R248 1-218-332-11 RES-CHIP 130K 5% 1/10W
R249 1-216-845-11 METAL CHIP 100K 5% 1/16W
R250 1-218-344-11 RES-CHIP 7.5K 5% 1/10W
R251 1-216-847-11 METAL CHIP 150K 5% 1/16W
R252 1-218-344-11 RES-CHIP 7.5K 5% 1/10W
R253 1-216-837-11 METAL CHIP 22K 5% 1/16W
R254 1-216-837-11 METAL CHIP 22K 5% 1/16W
< NETWORK RESISTOR >
RN201 1-233-576-11 RES, CHIP NETWORK 100
RN202 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT IN)
< VIBRATOR >
X101 1-767-518-11 VIBRATOR, CRYSTAL (33.8MHz)
******************************************************
1-683-060-21 JACK BOARD
*********
< CAPACITOR >
C850 1-127-888-21 CERAMIC 0.1uF 10% 50V
C851 1-127-888-21 CERAMIC 0.1uF 10% 50V
C853 1-162-294-31 CERAMIC 0.001uF 10% 50V
C854 1-162-294-31 CERAMIC 0.001uF 10% 50V
< JACK >
J301 1-764-106-21 JACK (PHONES)
< RESISTOR >
R850 1-249-417-11 CARBON 1K 5% 1/4W F
R851 1-249-421-11 CARBON 2.2K 5% 1/4W F
R852 1-249-421-11 CARBON 2.2K 5% 1/4W F
R853 1-249-425-11 CARBON 4.7K 5% 1/4W F
R854 1-249-429-11 CARBON 10K 5% 1/4W
R855 1-249-433-11 CARBON 22K 5% 1/4W
R856 1-249-437-11 CARBON 47K 5% 1/4W
< SWITCH >
S825 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE/DIRECTION,TUNING MODE)
(EXCEPT AEP,UK)
S825 1-571-760-11 SWITCH, KEY BOARD
(PLAY MODE/DIRECTION,TUNING MODE)
(AEP,UK)
S826 1-762-875-21 SWITCH, KEYBOARD (REPEAT,STEREO/MONO)
(EXCEPT AEP,UK)
S826 1-571-760-11 SWITCH, KEY BOARD (REPEAT,STEREO/MONO)
(AEP,UK)
S827 1-762-875-21 SWITCH, KEYBOARD (SYNCHRO MODE)
(EXCEPT AEP,UK)
S827 1-571-760-11 SWITCH, KEY BOARD (SYNCHRO MODE)
(AEP,UK)
S828 1-762-875-21 SWITCH, KEYBOARD (REC MODE)
(EXCEPT AEP,UK)
S828 1-571-760-11 SWITCH, KEY BOARD (REC MODE)(AEP,UK)
S829 1-762-875-21 SWITCH, KEYBOARD (ENTER/START)
(EXCEPT AEP,UK)
S829 1-571-760-11 SWITCH, KEY BOARD (ENTER/START)(AEP,UK)
S830 1-762-875-21 SWITCH, KEYBOARD (z MD)(EXCEPT AEP,UK)
S830 1-571-760-11 SWITCH, KEY BOARD (zMD) (AEP,UK)
S831 1-762-875-21 SWITCH, KEYBOARD (X TAPE)(EXCEPT AEP,UK)
S831 1-571-760-11 SWITCH, KEY BOARD (X TAPE)(AEP,UK)
S832 1-762-875-21 SWITCH, KEYBOARD (zTAPE)(EXCEPT AEP,UK)
S832 1-571-760-11 SWITCH, KEY BOARD (zTAPE) (AEP,UK)
******************************************************
1-674-336-12 LOADING BOARD
************
< CONNECTOR >
* CN151 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-786-203-11 SWITCH, LEVER (SLIDE) (TRAY OPEN)
******************************************************
A-4727-749-A MAIN BOARD, COMPLETE (AEP,UK)
A-4728-625-A MAIN BOARD, COMPLETE (EXCEPT AEP,UK)
******************
< BATTERY >
BT921 1-528-938-11 BATTERY, LITHIUM ION SECONDARY
< CAPACITOR >
C102 1-126-933-11 ELECT 100uF 20% 16V
C103 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
CD JACK LOADING MAIN
