Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
82
HCD-M10
BD
L143 1-216-296-11 SHORT 0
L144 1-216-296-11 SHORT 0
L145 1-216-296-11 SHORT 0
L146 1-469-855-21 FERRITE 0uH
L147 1-469-855-21 FERRITE 0uH
L161 1-500-245-11 FERRITE 0uH
L171 1-500-245-11 FERRITE 0uH
L180 1-469-855-21 FERRITE 0uH
L181 1-469-855-21 FERRITE 0uH
L182 1-500-245-11 FERRITE 0uH
L183 1-216-296-11 SHORT 0
L184 1-216-296-11 SHORT 0
< TRANSISTOR >
Q101 8-729-028-91 TRANSISTOR DTA144EUA-T106
Q121 8-729-028-91 TRANSISTOR DTA144EUA-T106
Q122 8-729-101-07 TRANSISTOR 2SB798-DL
Q131 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q132 8-729-903-10 TRANSISTOR FMW1
Q133 8-729-028-99 TRANSISTOR DTC114YUA-T106
Q133 8-729-402-93 TRANSISTOR UN5214
Q134 8-729-028-99 TRANSISTOR DTC114YUA-T106
Q181 8-729-018-75 TRANSISTOR 2SJ278MY
Q182 8-729-017-65 TRANSISTOR 2SK1764KY
< RESISTOR >
R101 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R102 1-216-853-11 METAL CHIP 470K 5% 1/16W
R103 1-216-863-11 RES-CHIP 3.3M 5% 1/10W
R104 1-216-853-11 METAL CHIP 470K 5% 1/16W
R105 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R106 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R107 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R108 1-216-833-11 METAL CHIP 10K 5% 1/16W
R109 1-216-845-11 METAL CHIP 100K 5% 1/16W
R110 1-216-845-11 METAL CHIP 100K 5% 1/16W
R111 1-216-833-11 METAL CHIP 10K 5% 1/16W
R112 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R113 1-216-833-11 METAL CHIP 10K 5% 1/16W
R114 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R115 1-216-833-11 METAL CHIP 10K 5% 1/16W
R116 1-216-839-11 METAL CHIP 33K 5% 1/16W
R117 1-216-837-11 METAL CHIP 22K 5% 1/16W
R118 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R119 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R120 1-218-889-11 METAL CHIP 56K 0.5% 1/10W
R121 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R122 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R123 1-216-819-11 METAL CHIP 680 5% 1/16W
R124 1-216-809-11 METAL CHIP 100 5% 1/16W
R125 1-216-815-11 METAL CHIP 330 5% 1/16W
R126 1-216-819-11 METAL CHIP 680 5% 1/16W
R127 1-216-845-11 METAL CHIP 100K 5% 1/16W
R128 1-219-724-11 METAL CHIP 1 1% 1/4W
R129 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R130 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R131 1-216-833-11 METAL CHIP 10K 5% 1/16W
R132 1-216-839-11 METAL CHIP 33K 5% 1/16W
R133 1-216-821-11 METAL CHIP 1K 5% 1/16W
R134 1-216-821-11 METAL CHIP 1K 5% 1/16W
R135 1-216-821-11 METAL CHIP 1K 5% 1/16W
R136 1-216-302-00 METAL CHIP 2.7 5% 1/10W
R138 1-216-833-11 METAL CHIP 10K 5% 1/16W
R150 1-216-833-11 METAL CHIP 10K 5% 1/16W
R151 1-216-833-11 METAL CHIP 10K 5% 1/16W
R153 1-216-833-11 METAL CHIP 10K 5% 1/16W
R155 1-216-864-11 METAL CHIP 0 5% 1/16W
R156 1-216-864-11 METAL CHIP 0 5% 1/16W
R158 1-216-809-11 METAL CHIP 100 5% 1/16W
R162 1-216-833-11 METAL CHIP 10K 5% 1/16W
R167 1-216-833-11 METAL CHIP 10K 5% 1/16W
R168 1-216-845-11 METAL CHIP 100K 5% 1/16W
R169 1-216-855-11 METAL CHIP 680K 5% 1/16W
R170 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R171 1-216-821-11 METAL CHIP 1K 5% 1/16W
R173 1-216-821-11 METAL CHIP 1K 5% 1/16W
R174 1-216-811-11 METAL CHIP 150 5% 1/16W
R177 1-216-805-11 METAL CHIP 47 5% 1/16W
R179 1-216-295-00 SHORT 0
R181 1-216-841-11 METAL CHIP 47K 5% 1/16W
R182 1-216-841-11 METAL CHIP 47K 5% 1/16W
R183 1-216-841-11 METAL CHIP 47K 5% 1/16W
R184 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R185 1-220-942-11 METAL CHIP 3.3 1% 1/4W
R195 1-216-833-11 METAL CHIP 10K 5% 1/16W
R196 1-216-833-11 METAL CHIP 10K 5% 1/16W
R197 1-216-833-11 METAL CHIP 10K 5% 1/16W
R218 1-216-864-11 METAL CHIP 0 5% 1/16W
< SWITCH >
S101 1-762-596-21 SWITCH, PUSH (1 KEY) (LIMIT IN)
S103 1-771-956-21 SWITCH, PUSH (1 KEY) (OUT)
S104 1-771-955-21 SWITCH, PUSH (1 KEY) (PLAY)
S105 1-771-955-21 SWITCH, PUSH (1 KEY) (REC)
< VIBRATOR >
X171 1-781-569-21 OSCILLATOR, CRYSTAL (90MHz)
******************************************************
1-683-065-11 BL (AMBER) BOARD (BLACK,SILVER)
***************
< DIODE >
D818 8-719-075-50 DIODE SELS6B14C-TP5
D819 8-719-075-50 DIODE SELS6B14C-TP5
D820 8-719-075-50 DIODE SELS6B14C-TP5
< RESISTOR >
R898 1-216-033-00 METAL CHIP 220 5% 1/10W
R899 1-216-033-00 METAL CHIP 220 5% 1/10W
R900 1-216-033-00 METAL CHIP 220 5% 1/10W
******************************************************
1-683-064-11 BL (WHITE) BOARD (WHITE)
***************
< CAPACITOR >
C880 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
BL (AMBER) BL (WHITE)
