Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
DOOR LED
< RESISTOR >
R691 1-249-402-11 CARBON 56 5% 1/4W F
R692 1-249-402-11 CARBON 56 5% 1/4W F
**************************************************************
* 1-663-974-11 CD MOTOR BOARD
****************
< CONNECTOR >
CN61 1-506-469-11 PIN, CONNECTOR 4P
**************************************************************
* 1-663-972-11 DISC SENSOR (R) BOARD
*********************
* 4-990-669-01 HOLDER (SENSOR)
7-685-132-19 SCREW +BTP 2.6X5 TYPE2 N-S
< TRANSISTOR >
Q51 8-729-926-31 PHOTO TRANISTOR PT483F1
**************************************************************
* 1-663-973-11 DISC SENSOR (S) BOARD
*********************
* 4-976-473-01 HOLDER (LED-S)
< CONNECTOR >
* CN53 1-568-951-11 PIN, CONNECTOR 2P
< DIODE >
D51 8-719-055-84 DIODE GL528VS1
< RESISTOR >
R54 1-249-409-11 CARBON 220 5% 1/4W F
**************************************************************
1-677-237-11 DOOR LED BOARD
***************
< CONNECTOR >
CN605A 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D697 8-719-080-87 DIODE L-934SYTK(CD DOOR)
< RESISTOR >
R694 1-249-407-11 CARBON 150 5% 1/4W F
**************************************************************
A-4475-078-A FRONT AMP BOARD, COMPLETE
***************************
< CAPACITOR >
C701 1-104-665-11 ELECT 100uF 20.00% 10V
C702 1-126-961-11 ELECT 2.2uF 20.00% 50V
C703 1-126-963-11 ELECT 4.7uF 20.00% 50V
C704 1-126-933-11 ELECT 100uF 20.00% 16V
C731 1-126-961-11 ELECT 2.2uF 20.00% 50V
C741 1-104-665-11 ELECT 100uF 20.00% 10V
C801 1-128-582-11 ELECT 10uF 20.00% 100V
C802 1-128-582-11 ELECT 10uF 20.00% 100V
C803 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C804 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C805 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C806 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C807 1-163-220-11 CERAMIC CHIP 3PF 0.25PF 50V
C808 1-163-220-11 CERAMIC CHIP 3PF 0.25PF 50V
C809 1-126-967-11 ELECT 47uF 20.00% 50V
C810 1-126-967-11 ELECT 47uF 20.00% 50V
C811 1-136-167-00 MYLAR 0.15uF 5.00% 50V
C812 1-136-167-00 MYLAR 0.15uF 5.00% 50V
C813 1-136-167-00 MYLAR 0.15uF 5.00% 50V
C814 1-136-167-00 MYLAR 0.15uF 5.00% 50V
C815 1-128-576-11 ELECT 100uF 20.00% 63V
C816 1-128-576-11 ELECT 100uF 20.00% 63V
C817 1-126-964-11 ELECT 10uF 20.00% 50V
C818 1-126-964-11 ELECT 10uF 20.00% 50V
C951 1-106-220-00 MYLAR 0.1uF 5% 100V
C952 1-106-220-00 MYLAR 0.1uF 5% 100V
C953 1-126-974-11 ELECT 3300uF 20.00% 50V
C954 1-126-974-11 ELECT 3300uF 20.00% 50V
< CONNECTOR >
CN301 1-568-855-11 SOCKET, CONNECTOR 12P
CN804 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D731 8-719-988-61 DIODE 1SS355TE-17
D732 8-719-988-61 DIODE 1SS355TE-17
D733 8-719-988-61 DIODE 1SS355TE-17
D751 8-719-988-61 DIODE 1SS355TE-17
D752 8-719-988-61 DIODE 1SS355TE-17
D801 8-719-988-61 DIODE 1SS355TE-17
D802
D803 8-719-988-61 DIODE 1SS355TE-17
D951 8-719-080-80 DIODE TS6B03G
< IC >
IC801 8-749-017-96 IC STK402-100
< TRANSISTOR >
Q701 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q702 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q703 8-729-026-39 TRANSISTOR 2SA933AS-QRT
Q711 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q712 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q721 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q731 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q732 8-729-026-39 TRANSISTOR 2SA933AS-QRT
Q733 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q741 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q742 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q743 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q801 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q802 8-729-119-78 TRANSISTOR 2SC1740S-QRT
< RESISTOR >
R701 1-216-081-00 METAL CHIP 22K 5% 1/10W
FRONT AMP
DISC SENSOR (R)CD LED CD MOTOR DISC SENSOR (S)
