71
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R702 1-216-089-91 RES-CHIP 47K 5% 1/10W
R704 1-216-089-91 RES-CHIP 47K 5% 1/10W
R705 1-216-073-00 METAL CHIP 10K 5% 1/10W
R706 1-216-089-91 RES-CHIP 47K 5% 1/10W
R707 1-216-073-00 METAL CHIP 10K 5% 1/10W
R708 1-216-033-00 METAL CHIP 220 5% 1/10W
R708 1-216-097-91 RES-CHIP 100K 5% 1/10W
R711 1-216-081-00 METAL CHIP 22K 5% 1/10W
R712 1-216-097-91 RES-CHIP 100K 5% 1/10W
R721 1-216-081-00 METAL CHIP 22K 5% 1/10W
R731 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R732 1-216-081-00 METAL CHIP 22K 5% 1/10W
R733 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R734 1-216-081-00 METAL CHIP 22K 5% 1/10W
R735 1-216-089-91 RES-CHIP 47K 5% 1/10W
R736 1-215-892-11 METAL OXIDE 1K 5% 2W
R737 1-216-073-00 METAL CHIP 10K 5% 1/10W
R738 1-216-073-00 METAL CHIP 10K 5% 1/10W
R741 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R742 1-216-085-00 METAL CHIP 33K 5% 1/10W
R743 1-216-073-00 METAL CHIP 10K 5% 1/10W
R744 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R745 1-216-081-00 METAL CHIP 22K 5% 1/10W
R746 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R747 1-216-049-91 RES-CHIP 1K 5% 1/10W
R751 1-216-089-91 RES-CHIP 47K 5% 1/10W
R752 1-216-089-91 RES-CHIP 47K 5% 1/10W
R761 1-216-091-00 METAL CHIP 56K 5% 1/10W
R762 1-216-081-00 METAL CHIP 22K 5% 1/10W
R801 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R802 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R803 1-216-089-91 RES-CHIP 47K 5% 1/10W
R804 1-216-089-91 RES-CHIP 47K 5% 1/10W
R805 1-216-089-91 RES-CHIP 47K 5% 1/10W
R806 1-216-089-91 RES-CHIP 47K 5% 1/10W
R807 1-216-049-91 RES-CHIP 1K 5% 1/10W
R808 1-216-049-91 RES-CHIP 1K 5% 1/10W
R809 1-216-049-91 RES-CHIP 1K 5% 1/10W
R810 1-216-049-91 RES-CHIP 1K 5% 1/10W
R811 1-216-077-91 RES-CHIP 15K 5% 1/10W
R812 1-216-077-91 RES-CHIP 15K 5% 1/10W
R813 1-220-893-11 METAL 0.22 10% 5W
R814 1-220-893-11 METAL 0.22 10% 5W
R815 1-216-097-91 RES-CHIP 100K 5% 1/10W
R816 1-216-097-91 RES-CHIP 100K 5% 1/10W
R817 1-260-075-81 CARBON 8.2 5% 1/2W
R818 1-260-075-81 CARBON 8.2 5% 1/2W
R819 1-249-427-11 CARBON 6.8K 5% 1/4W F
0 R829 1-212-881-11 FUSIBLE 100 5% 1/4W
0 R830 1-212-881-11 FUSIBLE 100 5% 1/4W
R831 1-260-316-51 CARBON 100 5% 1/2W
R832 1-260-316-51 CARBON 100 5% 1/2W
R833 1-260-316-51 CARBON 100 5% 1/2W
R834 1-260-316-51 CARBON 100 5% 1/2W
R835 1-260-316-51 CARBON 100 5% 1/2W
R836 1-260-316-51 CARBON 100 5% 1/2W
R837 1-220-893-11 METAL 0.22 10% 5W
R838 1-220-893-11 METAL 0.22 10% 5W
< RELAY >
RY731 1-515-920-11 RELAY (24V)
< THERMISTOR >
TH711 1-807-796-11 THERMISTOR
**************************************************************
1-677-246-11 FRONT SP TERM BOARD
********************
< CONNECTOR >
* CN802B 1-564-507-11 PLUG, CONNECTOR 4P
< TERMINAL BOARD >
JK801 1-694-730-11 TERMINAL BOARD (4P)(FRONT SPEAKER)
< COIL >
L701 1-419-686-11 COIL, AIR-CORE
L702 1-419-686-11 COIL, AIR-CORE
< RESISTOR >
R821 1-249-397-11 CARBON 22 5% 1/4W F
R822 1-249-397-11 CARBON 22 5% 1/4W F
R823 1-249-397-11 CARBON 22 5% 1/4W F
R824 1-249-397-11 CARBON 22 5% 1/4W F
**************************************************************
A-4475-067-A MAIN BOARD, COMPLETE (M100)
*********************
A-4475-085-A MAIN BOARD, COMPLETE (M300AV)
*********************
3-376-464-11 SCREW(+PTT 2.6X6),GROUND POINT
3-911-116-42 RIVET, PUSH
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< ANTENNA >
ANT1 1-694-731-11 TERMINAL BOARD (4P)
< CAPACITOR >
C1 1-161-494-00 CERAMIC 0.022uF 25V
C2 1-104-664-11 ELECT 47uF 20.00% 16V
C4 1-161-494-00 CERAMIC 0.022uF 25V
C5 1-161-494-00 CERAMIC 0.022uF 25V
C6 1-161-494-00 CERAMIC 0.022uF 25V
C7 1-162-847-11 CERAMIC 0.047uF 10.00% 16V
C8 1-162-847-11 CERAMIC 0.047uF 10.00% 16V
C9 1-104-664-11 ELECT 47uF 20.00% 16V
C23 1-162-600-11 CERAMIC 0.0047uF 30.00% 16V
C24 1-162-199-31 CERAMIC 10PF 5% 50V
C25 1-162-847-11 CERAMIC 0.047uF 10.00% 16V
C26 1-162-294-31 CERAMIC 0.001uF 10% 50V
C28 1-126-965-11 ELECT 22uF 20.00% 50V
C29 1-162-847-11 CERAMIC 0.047uF 10.00% 16V
C30 1-162-847-11 CERAMIC 0.047uF 10.00% 16V
FRONT AMP MAINFRONT SP TERM
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
To Next Page
