79
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R676 1-216-049-91 RES-CHIP 1K 5% 1/10W
R677 1-216-049-91 RES-CHIP 1K 5% 1/10W
< SWITCH >
S671 1-762-875-21 SWITCH, KEYBOARD(@/1)
S672 1-762-875-21 SWITCH, KEYBOARD(DISPLAY)
S673 1-762-875-21 SWITCH, KEYBOARD(CLOCK TIMER SET)
S674 1-762-875-21 SWITCH, KEYBOARD(TIMER SELECT)
**************************************************************
1-677-240-11 PANEL R BOARD
**************
< DIODE >
D682 8-719-080-71 DIODE L-1154ND(DSP)(M300AV)
< RESISTOR >
R682 1-216-033-00 METAL CHIP 220 5% 1/10W
R683 1-216-035-00 METAL CHIP 270 5% 1/10W
R684 1-216-039-00 METAL CHIP 390 5% 1/10W
R685 1-216-041-00 METAL CHIP 470 5% 1/10W
R686 1-216-045-00 METAL CHIP 680 5% 1/10W
R687 1-216-033-00 METAL CHIP 220 5% 1/10W
(M300AV)
< SWITCH >
S681 1-762-875-21 SWITCH, KEYBOARD(FUNCTION)
S682 1-762-875-21 SWITCH, KEYBOARD(DSP)
S683 1-762-875-21 SWITCH, KEYBOARD(DBFB)
S684 1-762-875-21 SWITCH, KEYBOARD(STEREO/MONO
(CONTINUE))
S685 1-762-875-21 SWITCH, KEYBOARD(TUNER MEMORY
(PROGRAM))
S686 1-762-875-21 SWITCH, KEYBOARD(DIRECTION(SHUFFLE))
**************************************************************
1-677-245-11 PHONE BOARD
*************
< JACK >
HP801 1-793-096-11 JACK (LARGE TYPE)(PHONES)
**************************************************************
A-4475-091-A REAR AMP BOARD, COMPLETE (M300AV)
**************************
< CAPACITOR >
C841 1-126-961-11 ELECT 2.2uF 20.00% 50V
C842 1-126-961-11 ELECT 2.2uF 20.00% 50V
C843 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C844 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C845 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C846 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C847 1-163-220-11 CERAMIC CHIP 3PF 0.25PF 50V
C848 1-163-220-11 CERAMIC CHIP 3PF 0.25PF 50V
C849 1-126-967-11 ELECT 47uF 20.00% 50V
C850 1-126-967-11 ELECT 47uF 20.00% 50V
C851 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C852 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C853 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C854 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C861 1-126-948-11 ELECT 100uF 20.00% 35V
C862 1-126-948-11 ELECT 100uF 20.00% 35V
C863 1-126-964-11 ELECT 10uF 20.00% 50V
C864 1-126-964-11 ELECT 10uF 20.00% 50V
C961 1-106-220-00 MYLAR 0.1uF 5% 100V
C962 1-106-220-00 MYLAR 0.1uF 5% 100V
C963 1-128-549-11 ELECT 3300uF 20.00% 35V
C964 1-128-549-11 ELECT 3300uF 20.00% 35V
< DIODE >
D771 8-719-988-61 DIODE 1SS355TE-17
D841 8-719-988-61 DIODE 1SS355TE-17
D842 8-719-988-61 DIODE 1SS355TE-17
D882 8-719-988-61 DIODE 1SS355TE-17
D883 8-719-024-99 DIODE 11ES2-NTA2B
D961 8-719-080-79 DIODE TS4B02G
< IC >
IC831 8-749-017-95 IC STK402-040
< COIL >
L841 1-419-686-11 COIL, AIR-CORE
L842 1-419-686-11 COIL, AIR-CORE
< TRANSISTOR >
Q291 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q292 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q771 8-729-026-39 TRANSISTOR 2SA933AS-QRT
Q772 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q841 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q842 8-729-119-78 TRANSISTOR 2SC1740S-QRT
< RESISTOR >
R258 1-216-049-91 RES-CHIP 1K 5% 1/10W
R259 1-216-097-91 RES-CHIP 100K 5% 1/10W
R260 1-216-097-91 RES-CHIP 100K 5% 1/10W
R262 1-216-073-00 METAL CHIP 10K 5% 1/10W
R291 1-216-049-91 RES-CHIP 1K 5% 1/10W
R293 1-216-073-00 METAL CHIP 10K 5% 1/10W
R771 1-216-073-00 METAL CHIP 10K 5% 1/10W
R772 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R773 1-216-081-00 METAL CHIP 22K 5% 1/10W
R774 1-249-406-11 CARBON 120 5% 1/4W F
R841 1-216-049-91 RES-CHIP 1K 5% 1/10W
R842 1-216-049-91 RES-CHIP 1K 5% 1/10W
R843 1-216-089-91 RES-CHIP 47K 5% 1/10W
R844 1-216-089-91 RES-CHIP 47K 5% 1/10W
R845 1-216-089-91 RES-CHIP 47K 5% 1/10W
R846 1-216-089-91 RES-CHIP 47K 5% 1/10W
R847 1-216-041-00 METAL CHIP 470 5% 1/10W
R848 1-216-041-00 METAL CHIP 470 5% 1/10W
R849 1-220-755-11 METAL 0.22 10% 2W
R850 1-220-755-11 METAL 0.22 10% 2W
R851 1-249-397-11 CARBON 22 5% 1/4W F
R852 1-249-397-11 CARBON 22 5% 1/4W F
R853 1-249-397-11 CARBON 22 5% 1/4W F
R854 1-249-397-11 CARBON 22 5% 1/4W F
R855 1-249-397-11 CARBON 22 5% 1/4W F
PANEL L PHONEPANEL R REAR AMP
