80
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R856 1-249-397-11 CARBON 22 5% 1/4W F
R857 1-249-397-11 CARBON 22 5% 1/4W F
R858 1-249-397-11 CARBON 22 5% 1/4W F
0 R863 1-212-881-11 FUSIBLE 100 5% 1/4W
0 R864 1-212-881-11 FUSIBLE 100 5% 1/4W
R865 1-216-049-91 RES-CHIP 1K 5% 1/10W
R866 1-216-049-91 RES-CHIP 1K 5% 1/10W
R867 1-216-097-91 RES-CHIP 100K 5% 1/10W
R868 1-216-097-91 RES-CHIP 100K 5% 1/10W
R869 1-216-077-91 RES-CHIP 15K 5% 1/10W
R870 1-216-077-91 RES-CHIP 15K 5% 1/10W
R871 1-216-085-00 METAL CHIP 33K 5% 1/10W
R872 1-216-083-00 METAL CHIP 27K 5% 1/10W
R874 1-249-425-11 CARBON 4.7K 5% 1/4W F
R895 1-220-755-11 METAL 0.22 10% 2W
R896 1-220-755-11 METAL 0.22 10% 2W
< RELAY >
RY771 1-515-920-11 RELAY (24V)
**************************************************************
1-677-249-11 REAR SP TERM BOARD (M300AV)
*******************
**************************************************************
1-677-247-11 SUB TRANS BOARD
****************
< CAPACITOR >
C931 1-164-159-11 CERAMIC 0.1uF 50V
C932 1-164-159-11 CERAMIC 0.1uF 50V
C933 1-164-159-11 CERAMIC 0.1uF 50V
C934 1-164-159-11 CERAMIC 0.1uF 50V
C936 1-126-942-61 ELECT 1000uF 20.00% 25V
C938 1-164-159-11 CERAMIC 0.1uF 50V
C939 1-104-665-11 ELECT 100uF 20.00% 10V
< CONNECTOR >
CN995 1-564-321-00 PIN, CONNECTOR 2P
CN997 1-506-468-11 PIN, CONNECTOR 3P
< DIODE >
D931 8-719-024-99 DIODE 11ES2-NTA2B
D932 8-719-024-99 DIODE 11ES2-NTA2B
D933 8-719-024-99 DIODE 11ES2-NTA2B
D934 8-719-024-99 DIODE 11ES2-NTA2B
D938 8-719-024-99 DIODE 11ES2-NTA2B
D939 8-719-024-99 DIODE 11ES2-NTA2B
D991 8-719-024-99 DIODE 11ES2-NTA2B
< IC >
IC931 8-759-701-56 IC NJM78M05FA
< TRANSISTOR >
Q991 8-729-029-66 TRANSISTOR DTC114ESA-TP
< RELAY >
0 RY991 1-755-409-11 RELAY
< TRANSFORMER >
0 T992 1-435-613-11 TRANSFORMER, POWER
**************************************************************
* 1-663-975-11 SW BOARD
**********
< CONNECTOR >
* CN54 1-568-941-11 PIN, CONNECTOR 3P
< SWITCH >
S51 1-571-958-11 SWITCH, PUSH (1 KEY)(UP)
S52 1-571-958-11 SWITCH, PUSH (1 KEY)(DOWN)
**************************************************************
* 1-663-971-11 TABLE SENSOR BOARD
*******************
< CONNECTOR >
* CN51 1-568-944-11 PIN, CONNECTOR 6P
CN52 1-506-481-11 PIN, CONNECTOR 2P
< IC >
IC51 8-749-924-18 PHOTO INTERRUPTER RPI-1391
IC52 8-749-924-18 PHOTO INTERRUPTER RPI-1391
IC53 8-749-924-18 PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R51 1-249-416-11 CARBON 820 5% 1/4W F
R52 1-249-416-11 CARBON 820 5% 1/4W F
R53 1-249-416-11 CARBON 820 5% 1/4W F
**************************************************************
1-677-242-11 TRANS BOARD
************
1-533-233- HOLDER, FUSE
< CAPACITOR >
C935 1-106-220-00 MYLAR 0.1uF 5% 100V
C937 1-126-968-11 ELECT 100uF 20.00% 50V
< CONNECTOR >
* CN992 1-564-519-11 PLUG, CONNECTOR 4P
* CN993 1-564-518-11 PLUG, CONNECTOR 3P(M300AV)
* CN994 1-564-520-11 PLUG, CONNECTOR 5P
< DIODE >
D935 8-719-024-99 DIODE 11ES2-NTA2B
< FUSE >
0 F992 1-533-420-11 FUSE, CLASS CYLINDRICAL (DIA.5) (5A 125V)
REAR AMP REAR SP TERM SUB TRANS
SW TABLE SENSOR TRANS
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
