Sony HCD-MC3AV - Unit Overview and Disassembly Steps; Front and Rear Panel Identification

— 5 —
SECTION 1
GENERAL
FRONT PANEL
576980
!¡
!™
!£
!¢
!¶
!•
@º!ª
!∞
@¡
@™
!§
#§
2
3
4
#£
#™
#¡
#∞
1
#¢
@£
@¢@∞@ª @•#º @§@¶
#¶
1 1/u button
2 DISPLAY/MEMO button
3 CLOCK TIMER SET button
4 TIMER SELECT button
5 TAPE A ª button
6 CD fl button
7 TAPE A · button
8 TAPE B ª button
9 TUNER/BAND button
0 TAPE B · button
!¡ SUR button
!™ DBFB button
!£ FUNCTION button
!¢ CONTINUE/DIRECTION button
!∞ PROGRAM/DOLBY-NR button
!§ SHUFFLE/STEREO/MONO button
!¶ REPEAT/TUNER MEMORY button
!• GROOVE button
!ª LOOP button
@º FLASH button
@¡ CD PLUS ONE button
@™ GROUP ENTRY button
@£ Numeric buttons
@¢ PHONES jack
@∞ VOLUME Knob
@§ STOP button
@¶ INPUT, SCAN, SEARCH, CHECK,
CLEAR, DELETE buttons
@• + )+ button
@ª SELECTOR button
#º =0 – button
#¡ ENTER button
#™ FILE SELECT button
#£ P PAUSE button
#¢ r REC button
#∞ CD SYNCHRO button
#§ HI-SPEED DUBBING button
#¶ PRO LOGIC button
