Sony HCD-MC3AV - Main and Power Amp Component Lists

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 97 —
< RESISTOR >
R54 1-249-409-11 CARBON 220 5% 1/4W F
************************************************************
1-674-316-11 DOOR LED BOARD
***************
< LED >
D633 8-719-075-49 LED FY3864X-J300K
************************************************************
* 1-663-975-11 DOOR SW BOARD
***************
< CONNECTOR >
* CN54 1-568-941-11 PIN, CONNECTOR 3P
< SWITCH >
S51 1-571-958-11 SWITCH, PUSH (1 KEY)(UP)
S52 1-571-958-11 SWITCH, PUSH (1 KEY)(DOWN)
************************************************************
A-4426-605-A FUNC BOARD, COMPLETE
*********************
< CONNECTOR >
CN604 1-506-481-11 PIN, CONNECTOR 2P
< LED>
D619 8-719-074-81 LED MAA3864X-J300(CD PLUS ONE)
D620 8-719-074-80 LED MVR3864X-J300K(1)
D621 8-719-074-80 LED MVR3864X-J300K(2)
D622 8-719-074-80 LED MVR3864X-J300K(3)
D623 8-719-074-80 LED MVR3864X-J300K(4)
D624 8-719-074-80 LED MVR3864X-J300K(5)
< RESISTOR >
R639 1-216-027-00 METAL CHIP 120 5% 1/10W
R640 1-216-029-00 METAL CHIP 150 5% 1/10W
R641 1-216-029-00 METAL CHIP 150 5% 1/10W
R642 1-216-029-00 METAL CHIP 150 5% 1/10W
R643 1-216-029-00 METAL CHIP 150 5% 1/10W
R644 1-216-029-00 METAL CHIP 150 5% 1/10W
R652 1-216-025-91 RES,CHIP 100 5% 1/10W
R652 1-216-029-00 METAL CHIP 150 5% 1/10W
R686 1-216-033-00 METAL CHIP 220 5% 1/10W
R687 1-216-035-00 METAL CHIP 270 5% 1/10W
R688 1-216-039-00 METAL CHIP 390 5% 1/10W
R689 1-216-041-00 METAL CHIP 470 5% 1/10W
R690 1-216-045-00 METAL CHIP 680 5% 1/10W
R691 1-216-047-91 RES,CHIP 820 5% 1/10W
R692 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R693 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R694 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R695 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R696 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R697 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R698 1-216-073-00 METAL CHIP 10K 5% 1/10W
< SWITCH >
S631 1-762-875-21 SWITCH, KEYBOARD(FUNCTION)
S632 1-762-875-21 SWITCH, KEYBOARD(CONTINUE)
S633 1-762-875-21 SWITCH, KEYBOARD(SHUFFLE)
S634 1-762-875-21 SWITCH, KEYBOARD(PROGRAM)
S635 1-762-875-21 SWITCH, KEYBOARD(REPEAT)
S636 1-762-875-21 SWITCH, KEYBOARD(CD PLUS ONE)
S637 1-762-875-21 SWITCH, KEYBOARD(LOOP)
S638 1-762-875-21 SWITCH, KEYBOARD(FLASH)
S639 1-762-875-21 SWITCH, KEYBOARD(GROUP ENTRY)
S640 1-762-875-21 SWITCH, KEYBOARD(1)
S641 1-762-875-21 SWITCH, KEYBOARD(2)
S642 1-762-875-21 SWITCH, KEYBOARD(3)
S643 1-762-875-21 SWITCH, KEYBOARD(4)
S644 1-762-875-21 SWITCH, KEYBOARD(5)
************************************************************
1-674-315-11 HP/MIC BOARD
***********
< JACK >
J781 1-793-096-11 JACK (LARGE TYPE) (PHONES)
************************************************************
* A-2007-732-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-124-286-00 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-11 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS119
D1002 8-719-911-19 DIODE 1SS119
< IC >
IC1001 8-749-014-38 IC PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 IC PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-900-65 TRANSISTOR DTA144ES
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-856-00 CARBON 11K 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
DOOR LEDDISC SENSOR (S)
DOOR SW FUNC HP/MIC LEAF SW
