Sony HCD-NE3 - Electrical Parts List

36
HCD-NE3
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP
BACK LIGHT BD
A-4750-277-A AMP BOARD, COMPLETE
********************
< CAPACITOR >
C501 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C503 1-126-947-11 ELECT 47uF 20% 35V
C505 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C506 1-126-947-11 ELECT 47uF 20% 35V
C507 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C509 1-126-949-11 ELECT 220uF 20% 35V
C510 1-126-949-11 ELECT 220uF 20% 35V
C511 1-136-177-00 FILM 1uF 5% 50V
C512 1-136-177-00 FILM 1uF 5% 50V
C513 1-136-177-00 FILM 1uF 5% 50V
C514 1-136-177-00 FILM 1uF 5% 50V
C516 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN501 1-564-507-11 PLUG, CONNECTOR 4P
< EARTH TERMINAL >
EP903 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC501 8-759-333-24 IC LM1876TF
< RESISTOR >
R501 1-216-821-11 METAL CHIP 1K 5% 1/10W
R502 1-216-841-11 METAL CHIP 47K 5% 1/10W
R503 1-216-819-11 METAL CHIP 680 5% 1/10W
R504 1-249-437-11 CARBON 47K 5% 1/4W
R505 1-216-841-11 METAL CHIP 47K 5% 1/10W
R506 1-216-821-11 METAL CHIP 1K 5% 1/10W
R507 1-216-833-11 METAL CHIP 10K 5% 1/10W
R508 1-216-819-11 METAL CHIP 680 5% 1/10W
R509 1-249-437-11 CARBON 47K 5% 1/4W
R511 1-216-839-11 METAL CHIP 33K 5% 1/10W
R512 1-216-839-11 METAL CHIP 33K 5% 1/10W
R514 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R515 1-216-373-81 METAL OXIDE 2.2 5% 2W F
0 R516 1-216-373-81 METAL OXIDE 2.2 5% 2W F
R517 1-216-842-11 METAL CHIP 56K 5% 1/10W
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
R518 1-216-841-11 METAL CHIP 47K 5% 1/10W
0 R519 1-215-889-00 METAL OXIDE 330 5% 2W F
0 R520 1-215-889-00 METAL OXIDE 330 5% 2W F
************************************************************
BACK LIGHT BOARD
****************
< LED >
D701 8-719-075-50 LED SELS6B14C-TP5 (LCD BACK LIGHT)
D702 8-719-075-50 LED SELS6B14C-TP5 (LCD BACK LIGHT)
D703 8-719-075-50 LED SELS6B14C-TP5 (LCD BACK LIGHT)
< RESISTOR >
R707 1-216-810-11 METAL CHIP 120 5% 1/10W
R708 1-216-810-11 METAL CHIP 120 5% 1/10W
R709 1-216-810-11 METAL CHIP 120 5% 1/10W
R710 1-216-810-11 METAL CHIP 120 5% 1/10W
R711 1-216-810-11 METAL CHIP 120 5% 1/10W
R712 1-216-810-11 METAL CHIP 120 5% 1/10W
************************************************************
A-4751-032-A BD BOARD, COMPLETE
******************
< CAPACITOR >
C10 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C11 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C14 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C15 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C16 1-115-156-11 CERAMIC CHIP 1uF 10V
C17 1-126-923-11 ELECT 220uF 20% 16V
C18 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C111 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C112 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C113 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C114 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C115 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C116 1-126-923-11 ELECT 220uF 20% 16V
C117 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C122 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C123 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C124 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
•Abbreviation
AR : Argentina model
AUS: Australian model
CND : Canadian model
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number
specified.
E51 : Chilean and Peruvian model
EA : Saudi Arabia model
KR : Korea model
MX : Mexican model
SP : Singapore model
TW : Taiwan model
