Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
39
HCD-NE3
R840 1-216-841-11 METAL CHIP 47K 5% 1/10W
R851 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R852 1-216-813-11 METAL CHIP 220 5% 1/10W
R853 1-216-815-11 METAL CHIP 330 5% 1/10W
R854 1-216-817-11 METAL CHIP 470 5% 1/10W
R855 1-216-819-11 METAL CHIP 680 5% 1/10W
R856 1-216-821-11 METAL CHIP 1K 5% 1/10W
R857 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R858 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R859 1-216-813-11 METAL CHIP 220 5% 1/10W
R860 1-216-815-11 METAL CHIP 330 5% 1/10W
R861 1-216-817-11 METAL CHIP 470 5% 1/10W
R862 1-216-819-11 METAL CHIP 680 5% 1/10W
R863 1-216-821-11 METAL CHIP 1K 5% 1/10W
R869 1-216-833-11 METAL CHIP 10K 5% 1/10W
R870 1-216-833-11 METAL CHIP 10K 5% 1/10W
R871 1-216-833-11 METAL CHIP 10K 5% 1/10W
R874 1-216-833-11 METAL CHIP 10K 5% 1/10W
R875 1-216-821-11 METAL CHIP 1K 5% 1/10W
(E, E51, EA, MX, AR)
R875 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(US, CND)
R875 1-216-864-11 SHORT CHIP 0 (AEP, UK)
R876 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(US, CND, E, E51, EA, MX, AR)
R876 1-216-864-11 SHORT CHIP 0 (SP, TW, KR, AUS)
R878 1-216-833-11 METAL CHIP 10K 5% 1/10W
R879 1-216-833-11 METAL CHIP 10K 5% 1/10W
R881 1-247-807-31 CARBON 100 5% 1/4W
R882 1-216-845-11 METAL CHIP 100K 5% 1/10W
R883 1-216-841-11 METAL CHIP 47K 5% 1/10W
R884 1-216-821-11 METAL CHIP 1K 5% 1/10W
R885 1-216-841-11 METAL CHIP 47K 5% 1/10W
R886 1-216-821-11 METAL CHIP 1K 5% 1/10W
R887 1-216-817-11 METAL CHIP 470 5% 1/10W
R890 1-216-813-11 METAL CHIP 220 5% 1/10W
R891 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R892 1-216-841-11 METAL CHIP 47K 5% 1/10W
R893 1-216-841-11 METAL CHIP 47K 5% 1/10W
R894 1-216-837-11 METAL CHIP 22K 5% 1/10W
R895 1-216-833-11 METAL CHIP 10K 5% 1/10W
R897 1-216-845-11 METAL CHIP 100K 5% 1/10W
R898 1-216-845-11 METAL CHIP 100K 5% 1/10W
< ROTARY ENCODER >
RV801 1-418-632-11 ENCODER, ROTARY (12 TYPE) (VOLUME)
< SWITCH >
S801 1-786-050-21 SWITCH, KEY BOARD (I/1)
S802 1-786-050-21 SWITCH, KEY BOARD (TAPE N)
S803 1-786-050-21 SWITCH, KEY BOARD (CD NX)
S804 1-786-050-21 SWITCH, KEY BOARD (TUNER, BAND)
S805 1-786-050-21 SWITCH, KEY BOARD (CD SYNCHRO)
S806 1-786-050-21 SWITCH, KEY BOARD (z REC PAUSE/START)
S807 1-786-050-21 SWITCH, KEY BOARD (PLAY MODE)
S808 1-786-050-21 SWITCH, KEY BOARD (x)
S809 1-786-050-21 SWITCH, KEY BOARD (TUNE – . m)
S810 1-786-050-21 SWITCH, KEY BOARD (TUNE + M >)
S811 1-786-050-21 SWITCH, KEY BOARD (DISPLAY)
S812 1-786-050-21 SWITCH, KEY BOARD (BASS/TREBLE)
S813 1-786-050-21 SWITCH, KEY BOARD (DSGX)
< VIBRATOR >
X801 1-760-252-12 VIBRATOR, CRYSTAL (32.768kHz)
X802 1-795-004-21 VIBRATOR, CERAMIC (10MHz)
************************************************************
HP BOARD
*********
< CAPACITOR >
C520 1-127-876-21 CERAMIC 0.01uF 10% 50V
C521 1-127-876-21 CERAMIC 0.01uF 10% 50V
< JACK >
J301 1-793-829-11 JACK, HEADPHONE (PHONES)
************************************************************
A-4750-275-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C102 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C103 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C104 1-104-665-11 ELECT 100uF 20% 25V
C106 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C107 1-126-961-11 ELECT 2.2uF 20% 50V
C108 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C109 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C110 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C111 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C112 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C113 1-126-957-11 ELECT 0.22uF 20% 50V
C114 1-126-959-11 ELECT 0.47uF 20% 50V
C115 1-126-963-11 ELECT 4.7uF 20% 50V
C116 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C117 1-164-730-11 CERAMIC CHIP 0.0012uF 10% 50V
C118 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C119 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C121 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C126 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C127 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C132 1-126-963-11 ELECT 4.7uF 20% 50V
C133 1-130-491-00 MYLAR 0.047uF 5% 50V
C134 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C135 1-126-964-11 ELECT 10uF 20% 50V
C136 1-126-964-11 ELECT 10uF 20% 50V
C201 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C202 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C203 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CONTROL HP MAIN
