Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
42
HCD-NE3
R359 1-260-330-11 CARBON 1.5K 5% 1/2W
0 R360 1-219-787-17 FUSIBLE 5.6 5% 1/4W F
0 R361 1-219-787-17 FUSIBLE 5.6 5% 1/4W F
R362 1-216-836-11 METAL CHIP 18K 5% 1/10W
R363 1-216-836-11 METAL CHIP 18K 5% 1/10W
R364 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R365 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R366 1-216-837-11 METAL CHIP 22K 5% 1/10W
R367 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R368 1-216-833-11 METAL CHIP 10K 5% 1/10W
R370 1-216-833-11 METAL CHIP 10K 5% 1/10W
R371 1-216-833-11 METAL CHIP 10K 5% 1/10W
R372 1-216-844-11 METAL CHIP 82K 5% 1/10W
R373 1-216-833-11 METAL CHIP 10K 5% 1/10W
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
************************************************************
A-1055-614-A POWER BOARD, COMPLETE (E, E51, SP)
A-1056-003-A POWER BOARD, COMPLETE (AR, AUS)
A-1056-266-A POWER BOARD, COMPLETE (MX, TW)
A-1056-495-A POWER BOARD, COMPLETE (EA)
A-1056-526-A POWER BOARD, COMPLETE (KR)
A-4750-273-A POWER BOARD, COMPLETE (AEP, UK)
A-4751-335-A POWER BOARD, COMPLETE (US, CND)
***********************
< CAPACITOR >
C901 1-136-165-00 FILM 0.1uF 5% 50V
C902 1-136-165-00 FILM 0.1uF 5% 50V
C903 1-136-165-00 FILM 0.1uF 5% 50V
C905 1-161-055-00 CERAMIC 0.022uF 10% 50V
C906 1-161-055-00 CERAMIC 0.022uF 10% 50V
C907 1-161-055-00 CERAMIC 0.022uF 10% 50V
C908 1-161-055-00 CERAMIC 0.022uF 10% 50V
C909 1-161-055-00 CERAMIC 0.022uF 10% 50V
C910 1-161-055-00 CERAMIC 0.022uF 10% 50V
C911 1-161-055-00 CERAMIC 0.022uF 10% 50V
C912 1-161-055-00 CERAMIC 0.022uF 10% 50V
0 C913 1-113-925-11 CERAMIC 0.01uF 20% 250V
C914 1-126-947-11 ELECT 47uF 20% 35V
C915 1-136-497-81 FILM 0.1uF 5% 50V
(EA, MX, TW)
C915 1-136-165-00 FILM 0.1uF 5% 50V
(EXCEPT EA, MX, TW)
< CONNECTOR >
* CN901 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
* CN902 1-564-511-11 PLUG, CONNECTOR 8P
(EXCEPT EA, MX, TW, KR)
* CN902 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
(EA, MX, TW, KR)
< DIODE >
D906 8-719-991-33 DIODE 1SS133T-77
D907 8-719-991-33 DIODE 1SS133T-77
D908 8-719-991-33 DIODE 1SS133T-77
D909 8-719-991-33 DIODE 1SS133T-77
D910 8-719-991-33 DIODE 1SS133T-77
D911 8-719-063-79 DIODE 1N4002B
D912 8-719-063-79 DIODE 1N4002B
D913 8-719-063-79 DIODE 1N4002B
D914 8-719-063-79 DIODE 1N4002B
D916 8-719-046-47 DIODE 1N5401TM
D917 8-719-046-47 DIODE 1N5401TM
D918 8-719-046-47 DIODE 1N5401TM
D919 8-719-046-47 DIODE 1N5401TM
D920 8-719-991-33 DIODE 1SS133T-77
D921 8-719-991-33 DIODE 1SS133T-77
D922 8-719-050-84 DIODE RB441Q-40T-77
D923 8-719-991-33 DIODE 1SS133T-77
D924 8-719-991-33 DIODE 1SS133T-77
< LINE FILTER >
0 LF901 1-402-663-11 TRANSFORMER, LINE FILTER (LFT)
< RESISTOR >
R901 1-249-437-11 CARBON 47K 5% 1/4W
R902 1-249-437-11 CARBON 47K 5% 1/4W
0 R903 1-219-237-51 CARBON 3.3M 5% 1/2W F
(US, CND)
R904 1-249-421-11 CARBON 2.2K 5% 1/4W
R905 1-249-421-11 CARBON 2.2K 5% 1/4W
R906 1-249-417-11 CARBON 1K 5% 1/4W
(US, CND, AEP, UK, KR)
R906 1-249-418-11 CARBON 1.2K 5% 1/4W
(EXCEPT US, CND, AEP, UK, KR)
R910 1-219-120-11 FUSIBLE 0.15 5% 1/4W
< RELAY >
0 RY901 1-755-276-11 RELAY, POWER
< SWITCH >
0 S901 1-571-309-11 SWITCH (VOLTAGE DETECT) (E, E51, EA, SP)
< TRANSFORMER >
0 T901 1-439-772-11 TRANSFORMER, POWER
(EXCEPT US, CND, AEP, UK, KR)
0 T901 1-439-779-11 TRANSFORMER, POWER (AEP, UK, KR)
0 T901 1-439-781-11 TRANSFORMER, POWER (US, CND)
************************************************************
REG BOARD
*********
< CAPACITOR >
C306 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C307 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< IC >
IC305 8-759-231-57 IC TA7810S
IC306 8-759-450-49 IC BA07T
************************************************************
MAIN POWER REG
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
