Sony HCD-PX333 - MD Digital Board; Holder (Bu) Assy

28
HCD-PX333
3-17. MD DIGITAL BOARD
3-18. HOLDER (BU) ASSY
3 screw (+BV 3 × 10)
8 MD DIGITAL board
4 two claws
5
1 wire (flat type)(17 core)
(CN1004)
2 wire (flat type)(27 core)
(CN1003)
6 wire (flat type)(31 core)
(CN1001)
7 connector 5p (CN1005)
A
1 Rotate the lever (SW) in the direction of arrow A .
3
2 screw (+PTPWH M2.6),
floating
4 holder (BU) assy
