6-3. PRINTED WIRING BOARD BD (CD) BOARD
Printed wiring board of BD (CD) board is shown only for
referring, because CD base unit is replaced as a block.
• See page 55 for Circuit Boards Location.
(SIDE A)
12
(12)
MD DIGITAL
BOARD
CN1002
(Page 61)
(SIDE B)
TO
12
(12)
