• WAVEFORMS
1 IC101 wg (MDP)
(CD Play Mode)
4 IC101 rd (RFDC)
(CD Play Mode)
2 IC101 el (FE)
(CD Play Mode)
3 IC101 ra (TE)
(CD Play Mode)
6 IC101 us (XTAO)
5 IC101 t; (RFAC)
(CD Play Mode)
2.6 Vp-p
7.9
µ s
200 mVp-p
180 mVp-p
1.2 ± 0.2 Vp-p
1.2 Vp-p
3.1 Vp-p
29 ns
1 IC101 1 (I), 2 (J)
(MD Play Mode)
4 IC151 qh (OSCI)
2 IC101 4 (A)
(MD Play Mode)
3 IC101 8 (E), 9 (F)
(MD Play Mode)
5 IC151 o; (FS4)
0.5 Vp-p
0.1 Vp-p
0.06 Vp-p
3.1 Vp-p
22 ns
3.2 Vp-p
56.6
µ s
1 IC1101 el (X1)
4 IC1006 ej
(I2SLRCKOUT)
2 IC1006 wl (CLKOUT)
3 IC1006 ed
(I2SBCKOUT)
5 IC1001 ws (XIN)
1.5 Vp-p
62.4 ns
4.3 Vp-p
88.5 ns
3.7 Vp-p
354 ns
3.6 Vp-p
22.7
µ s
2.6 Vp-p
100 ns
1 IC501 eh (XTOUT)
2 IC501 ek (XOUT)
3.4 V
30.5 µ s
3.3 V
62.4 ns
BD (CD) BOARD BD (MD) BOARD
MD DIGITAL BOARD MAIN BOARD
