NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 61 —
SECTION 7
ELECTRICAL PARTS LIST
* 1-670-391-11 AC POWER BOARD
***************
* 1-533-213-31 HOLDER, FUSE
< FUSE >
! F001 1-532-504-21 FUSE 250V/4A
< RESISTOR >
! R001 1-202-727-00 CARBON 4.7M 5% 1/3W
************************************************************
* A-4414-924-A CD DECODER BOARD, COMPLETE
***************************
< CAPACITOR >
C02 1-126-963-11 ELECT 4.7uF 20% 50V
C03 1-126-933-11 ELECT 100uF 20% 10V
C04 1-162-306-11 CERAMIC 0.01uF 20% 16V
C04A 1-164-159-11 CERAMIC 0.1uF 50V
C05 1-136-159-00 FILM 0.033uF 5% 50V
C06 1-162-306-11 CERAMIC 0.01uF 20% 16V
C07 1-136-159-00 FILM 0.033uF 5% 50V
C07A 1-162-199-31 CERAMIC 10PF 5% 50V
C08 1-161-494-00 CERAMIC 0.022uF 25V
C09 1-126-959-11 ELECT 0.47uF 20% 50V
C10 1-162-306-11 CERAMIC 0.01uF 20% 16V
C11 1-126-933-11 ELECT 100uF 20% 10V
C11A 1-164-159-11 CERAMIC 0.1uF 50V
C12 1-162-306-11 CERAMIC 0.01uF 20% 16V
C13 1-164-159-11 CERAMIC 0.1uF 50V
C14 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C15 1-164-159-11 CERAMIC 0.1uF 50V
C16 1-136-159-00 FILM 0.033uF 5% 50V
C17 1-136-165-00 FILM 0.1uF 5% 50V
C18 1-164-159-11 CERAMIC 0.1uF 50V
C19 1-126-963-11 ELECT 4.7uF 20% 50V
C20 1-162-306-11 CERAMIC 0.01uF 20% 16V
C21 1-136-157-00 FILM 0.022uF 5% 50V
C22 1-126-933-11 ELECT 100uF 20% 10V
C23 1-164-159-11 CERAMIC 0.1uF 50V
C24 1-126-965-11 ELECT 22uF 20% 50V
C25 1-126-960-11 ELECT 1uF 20% 50V
C26 1-161-494-00 CERAMIC 0.022uF 25V
C27 1-162-306-11 CERAMIC 0.01uF 20% 16V
C28 1-164-159-11 CERAMIC 0.1uF 50V
C30 1-126-933-11 ELECT 100uF 20% 10V
C30A 1-164-159-11 CERAMIC 0.1uF 50V
C31 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C32 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C33 1-162-306-11 CERAMIC 0.01uF 20% 16V
C34 1-162-286-31 CERAMIC 220PF 10% 50V
C35 1-162-306-11 CERAMIC 0.01uF 20% 16V
C36 1-126-963-11 ELECT 4.7uF 20% 50V
C37 1-164-159-11 CERAMIC 0.1uF 50V
C37A 1-126-925-11 ELECT 470uF 20% 10V
C38 1-102-958-00 CERAMIC 20PF 5% 50V
C39 1-102-958-00 CERAMIC 20PF 5% 50V
C41A 1-162-294-31 CERAMIC 0.001uF 10% 50V
C42A 1-162-294-31 CERAMIC 0.001uF 10% 50V
C44A 1-162-294-31 CERAMIC 0.001uF 10% 50V
C45 1-126-934-11 ELECT 220uF 20% 10V
C46 1-126-933-11 ELECT 100uF 20% 10V
C51 1-162-288-31 CERAMIC 330PF 10% 50V
C51A 1-126-959-11 ELECT 0.47uF 20% 50V
C52 1-162-288-31 CERAMIC 330PF 10% 50V
C53 1-162-284-31 CERAMIC 150PF 10% 50V
C54 1-162-284-31 CERAMIC 150PF 10% 50V
C55 1-162-284-31 CERAMIC 150PF 10% 50V
C56 1-162-284-31 CERAMIC 150PF 10% 50V
C57 1-126-961-11 ELECT 2.2uF 20% 50V
C58 1-126-961-11 ELECT 2.2uF 20% 50V
C59 1-162-294-31 CERAMIC 0.001uF 10% 50V
C60 1-162-294-31 CERAMIC 0.001uF 10% 50V
C81 1-164-159-11 CERAMIC 0.1uF 50V
C83 1-164-159-11 CERAMIC 0.1uF 50V
C84 1-162-282-31 CERAMIC 100PF 10% 50V
C85 1-162-292-31 CERAMIC 680PF 10% 50V
C86 1-162-282-31 CERAMIC 100PF 10% 50V
C86A 1-161-494-00 CERAMIC 0.022uF 25V
C87 1-162-282-31 CERAMIC 100PF 10% 50V
C88 1-162-282-31 CERAMIC 100PF 10% 50V
C90 1-161-494-00 CERAMIC 0.022uF 25V
C90A 1-164-159-11 CERAMIC 0.1uF 50V
C98 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CN01 1-580-475-11 SOCKET, CONNECTOR 16P
CN05 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN06 1-695-366-21 PIN, CONNECTOR (PC BOARD) 5P
CN09 1-770-528-31 PIN, CONNECTOR (PC BOARD) 21P
AC POWER
CD DECODER
• Abbreviation
AED : North European
G : German
