Sony HCD-RX33 - 2 Disassembly; CD Door; CD Mechanism Deck

— 5 —
SECTION 2
DISASSEMBLY
Two claws
1 Pull out the CD tray and remove the CD door
with releasing claws into the direction of arrow.
2 CD door
2-1. CD DOOR
Note : Follow the disassembly procedure in the numerical order given.
6 CD mechanism deck
1 Two screws (+B 3 × 8)
3 Two screws (+BVTP 3 × 10)
2 Screw (+PTPWH 3 × 10)
2 Screw (+PTPWH 3 × 10)
4 Flat type wire (CN09)
5 Harness (CN302)
2-2. CD MECHANISM DECK
