Sony HCD-RX55 - Main, Motor, and Panel Parts List (Resistors, Switches)

Ref. No. Part No. Description Remarks
— 81 —
Ref. No. Part No. Description Remarks
R337 1-247-704-11 CARBON 220 5% 1/4W F
R338 1-247-708-11 CARBON 470 5% 1/4W F
R339 1-247-897-11 CARBON 560K 5% 1/4W
R340 1-247-897-11 CARBON 560K 5% 1/4W
R341 1-249-418-11 CARBON 1.2K 5% 1/4W F
R342 1-249-418-11 CARBON 1.2K 5% 1/4W F
R344 1-247-839-11 CARBON 2.2K 5% 1/4W
R345 1-247-839-11 CARBON 2.2K 5% 1/4W
R346 1-247-843-11 CARBON 3.3K 5% 1/4W
R347 1-247-843-11 CARBON 3.3K 5% 1/4W
R348 1-247-863-11 CARBON 22K 5% 1/4W
R349 1-247-863-11 CARBON 22K 5% 1/4W
R352 1-247-871-11 CARBON 47K 5% 1/4W
R353 1-247-871-11 CARBON 47K 5% 1/4W
R354 1-247-863-11 CARBON 22K 5% 1/4W
R355 1-247-863-11 CARBON 22K 5% 1/4W
R356 1-247-839-11 CARBON 2.2K 5% 1/4W
R357 1-247-839-11 CARBON 2.2K 5% 1/4W
R358 1-247-871-11 CARBON 47K 5% 1/4W
R359 1-247-871-11 CARBON 47K 5% 1/4W
R360 1-247-855-11 CARBON 10K 5% 1/4W
R361 1-247-855-11 CARBON 10K 5% 1/4W
R364 1-247-863-11 CARBON 22K 5% 1/4W
R365 1-247-863-11 CARBON 22K 5% 1/4W
R366 1-247-871-11 CARBON 47K 5% 1/4W
R367 1-247-879-11 CARBON 100K 5% 1/4W
R368 1-247-847-11 CARBON 4.7K 5% 1/4W
R369 1-247-847-11 CARBON 4.7K 5% 1/4W
R370 1-247-883-00 CARBON 150K 5% 1/4W
R371 1-247-883-00 CARBON 150K 5% 1/4W
R372 1-247-887-00 CARBON 220K 5% 1/4W
R373 1-247-887-00 CARBON 220K 5% 1/4W
R375 1-247-710-11 CARBON 560 5% 1/4W F
R378 1-247-867-11 CARBON 33K 5% 1/4W
R379 1-247-867-11 CARBON 33K 5% 1/4W
R380 1-249-427-11 CARBON 6.8K 5% 1/4W F
R381 1-249-427-11 CARBON 6.8K 5% 1/4W F
R383 1-259-634-11 CARBON 18 2% 1W
R384 1-249-469-11 CARBON 100K 5% 1/4W
R385 1-247-879-11 CARBON 100K 5% 1/4W
R386 1-249-469-11 CARBON 100K 5% 1/4W
R387 1-247-879-11 CARBON 100K 5% 1/4W
R388 1-249-469-11 CARBON 100K 5% 1/4W
R389 1-247-879-11 CARBON 100K 5% 1/4W
R390 1-249-469-11 CARBON 100K 5% 1/4W
R391 1-247-879-11 CARBON 100K 5% 1/4W
R394 1-247-710-11 CARBON 560 5% 1/4W F
R395 1-247-863-11 CARBON 22K 5% 1/4W
R396 1-247-863-11 CARBON 22K 5% 1/4W
R401 1-247-717-11 CARBON 2.2K 5% 1/4W F
R402 1-249-417-11 CARBON 1K 5% 1/4W F
R404 1-247-871-11 CARBON 47K 5% 1/4W
R405 1-247-871-11 CARBON 47K 5% 1/4W
R406 1-247-855-11 CARBON 10K 5% 1/4W
R407 1-247-855-11 CARBON 10K 5% 1/4W
R408 1-247-871-11 CARBON 47K 5% 1/4W
R409 1-247-871-11 CARBON 47K 5% 1/4W
R410 1-247-710-11 CARBON 560 5% 1/4W F
R411 1-247-710-11 CARBON 560 5% 1/4W F
R412 1-247-694-11 CARBON 33 5% 1/4W F
R413 1-247-694-11 CARBON 33 5% 1/4W F
R414 1-247-839-11 CARBON 2.2K 5% 1/4W
R415 1-247-839-11 CARBON 2.2K 5% 1/4W
R416 1-247-871-11 CARBON 47K 5% 1/4W
R417 1-247-855-11 CARBON 10K 5% 1/4W
R420 1-249-413-11 CARBON 470 5% 1/4W F
R422 1-249-417-11 CARBON 1K 5% 1/4W F
R430 1-249-417-11 CARBON 1K 5% 1/4W F
R431 1-247-883-00 CARBON 150K 5% 1/4W
R432 1-247-871-11 CARBON 47K 5% 1/4W
R433 1-247-871-11 CARBON 47K 5% 1/4W
R434 1-247-839-11 CARBON 2.2K 5% 1/4W
R435 1-247-839-11 CARBON 2.2K 5% 1/4W
R436 1-247-855-11 CARBON 10K 5% 1/4W
R437 1-249-427-11 CARBON 6.8K 5% 1/4W F
R438 1-249-427-11 CARBON 6.8K 5% 1/4W F
R450 1-247-855-11 CARBON 10K 5% 1/4W
R451 1-247-863-11 CARBON 22K 5% 1/4W
R452 1-249-417-11 CARBON 1K 5% 1/4W F
R453 1-247-839-11 CARBON 2.2K 5% 1/4W
R454 1-247-839-11 CARBON 2.2K 5% 1/4W
R455 1-247-855-11 CARBON 10K 5% 1/4W
R456 1-247-855-11 CARBON 10K 5% 1/4W
R457 1-247-855-11 CARBON 10K 5% 1/4W
R467 1-249-417-11 CARBON 1K 5% 1/4W F
< ADJ >
SFR101 1-228-995-00 RES, ADJ, METAL 22K
< SWITCH >
SW101 1-762-735-11 SWITCH, SLIDE (E,AUS,SP,MY,TW)
< TRANSFORMER >
T101 1-429-553-11 TRANSFORMER, FM IFT
T102 1-429-554-11 TRANSFORMER, AM IFT
< VIBRATOR >
X101 1-579-585-11 VIBRATOR, CRYSTAL 7.2MHz
************************************************************
* 1-639-678-12 MOTOR (6P)(S)BOARD
*******************
< CONNECTOR >
* CN1 1-564-722-11 PIN,CONNECTOR (SMALL TYPE)6P
< MOTOR >
M101 X-2625-877-1 MOTOR ASSY (SPINDLE)
M102 X-2625-769-1 MOTOR ASSY (SLED)
< SWITCH >
S1 1-572-085-11 SWITCH,LEAF(LIMIT)
************************************************************
* A-4405-479-A PANEL BOARD, COMPLETE (US,CND,MX)
***********************
* A-4405-485-A PANEL BOARD, COMPLETE (E,AUS,SP,MY,TW)
***********************
* 4-210-620-01 HOLDER, DISPLAY
MAIN
PANELMOTOR (6P)(S)
