Sony HCD-RX55 - Panel Section Electrical Parts List (Capacitors, ICs, LEDs)

Ref. No. Part No. Description Remarks
— 82 —
Ref. No. Part No. Description Remarks
< CAPACITOR >
C601 1-126-916-11 ELECT 1000uF 20% 6.3V
C602 1-161-494-00 CERAMIC 0.022uF 25V
C603 1-164-159-11 CERAMIC 0.1uF 50V
C604 1-126-933-11 ELECT 100uF 20% 16V
C605 1-126-967-11 ELECT 47uF 20% 16V
C606 1-164-159-11 CERAMIC 0.1uF 50V
C607 1-126-961-11 ELECT 2.2uF 20% 50V
C608 1-126-960-11 ELECT 1uF 20% 50V
C609 1-164-159-11 CERAMIC 0.1uF 50V
C610 1-126-964-11 ELECT 10uF 20% 50V
C611 1-161-494-00 CERAMIC 0.022uF 25V
C612 1-102-510-11 CERAMIC 12PF 5% 50V
C613 1-102-510-11 CERAMIC 12PF 5% 50V
C614 1-126-960-11 ELECT 1uF 20% 50V
C615 1-126-019-11 ELECT 10uF 20% 25V
C616 1-110-671-31 FILM 0.047uF
C617 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C618 1-126-964-11 ELECT 10uF 20% 50V
C619 1-161-494-00 CERAMIC 0.022uF 25V
C620 1-161-494-00 CERAMIC 0.022uF 25V
C621 1-126-964-11 ELECT 10uF 20% 50V
C622 1-126-964-11 ELECT 10uF 20% 50V
C623 1-162-294-31 CERAMIC 0.001uF 10% 50V
C633 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C634 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C635 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C636 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C637 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C638 1-162-600-11 CERAMIC 0.0047uF 30% 16V
< CONNECTOR >
CN601 1-770-331-11 CONNECTOR, D-SUB (11W1)
CN602 1-568-861-11 SOCKET, CONNECTOR 18P
CN602 8-719-031-85 DIODE 1N4002L
< DIODE >
D601 8-719-911-19 DIODE 1SS119
D602 8-719-031-85 DIODE 1N4002L
D603 8-719-911-19 DIODE 1SS119
D604 8-719-911-19 DIODE 1SS119
D605 8-719-911-19 DIODE 1SS119
D607 8-719-987-63 DIODE 1N4148
D608 8-719-911-19 DIODE 1SS119
D609 8-719-987-63 DIODE 1N4148
D610 8-719-911-19 DIODE 1SS119
D611 8-719-911-19 DIODE 1SS119
D612 8-719-991-33 DIODE 1SS133
D613 8-719-911-19 DIODE 1SS119
D614 8-719-991-33 DIODE 1SS133
D615 8-719-991-33 DIODE 1SS133
D616 8-719-911-19 DIODE 1SS119
D617 8-719-991-33 DIODE 1SS133
D618 8-719-991-33 DIODE 1SS133
D619 8-719-991-33 DIODE 1SS133
< FLUORESCENT INDICATOR >
FLD601 1-517-761-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 8-759-540-23 IC uPD78020SGF-043-3BA
IC602 8-759-275-23 IC BU2092
IC603 8-759-473-61 IC BU2114
< COIL >
L601 1-408-096-00 INDUCTOR 470uH
L602 1-408-611-31 INDUCTOR 47mH
L603 1-408-611-31 INDUCTOR 47mH
< LED >
LED605 8-719-044-69 DIODE SEL1910DTP3
LED606 8-719-044-69 DIODE SEL1910DTP3
LED607 8-719-921-01 DIODE EBR5534S
LED608 8-719-312-70 DIODE SEL1410G
LED609 8-719-312-70 DIODE SEL1410G
LED610 8-719-312-70 DIODE SEL1410G
LED611 8-719-312-70 DIODE SEL1410G
< TRANSISTOR >
Q601 8-729-194-57 TRANSISTOR 2SC945-P
Q602 8-729-194-57 TRANSISTOR 2SC945-P
Q603 8-729-194-57 TRANSISTOR 2SC945-P
Q604 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q605 8-729-194-57 TRANSISTOR 2SC945-P
Q606 8-729-900-63 TRANSISTOR DTA124ES
Q607 8-729-900-63 TRANSISTOR DTA124ES
Q608 8-729-900-63 TRANSISTOR DTA124ES
Q609 8-729-900-63 TRANSISTOR DTA124ES
Q610 8-729-900-63 TRANSISTOR DTA124ES
Q611 8-729-900-63 TRANSISTOR DTA124ES
Q612 8-729-900-63 TRANSISTOR DTA124ES
Q613 8-729-900-63 TRANSISTOR DTA124ES
< RESISTOR >
R601 1-247-871-11 CARBON 47K 5% 1/4W
R602 1-249-417-11 CARBON 1K 5% 1/4W F
R603 1-247-871-11 CARBON 47K 5% 1/4W
R604 1-249-417-11 CARBON 1K 5% 1/4W F
R605 1-247-871-11 CARBON 47K 5% 1/4W
R606 1-247-839-11 CARBON 2.2K 5% 1/4W
R607 1-247-839-11 CARBON 2.2K 5% 1/4W
R608 1-247-839-11 CARBON 2.2K 5% 1/4W
R609 1-247-855-11 CARBON 10K 5% 1/4W
R610 1-247-713-11 CARBON 1K 5% 1/4W F
R611 1-249-431-11 CARBON 15K 5% 1/4W
R612 1-247-871-11 CARBON 47K 5% 1/4W
R613 1-249-417-11 CARBON 1K 5% 1/4W F
R614 1-249-417-11 CARBON 1K 5% 1/4W F
R615 1-247-713-11 CARBON 1K 5% 1/4W F
R616 1-247-713-11 CARBON 1K 5% 1/4W F
R617 1-247-713-11 CARBON 1K 5% 1/4W F
R618 1-247-713-11 CARBON 1K 5% 1/4W F
R619 1-247-855-11 CARBON 10K 5% 1/4W
R620 1-247-855-11 CARBON 10K 5% 1/4W
R621 1-247-725-11 CARBON 10K 5% 1/4W F
R622 1-247-855-11 CARBON 10K 5% 1/4W
R623 1-247-855-11 CARBON 10K 5% 1/4W
R624 1-247-855-11 CARBON 10K 5% 1/4W
R625 1-247-847-11 CARBON 4.7K 5% 1/4W
PANEL
