Sony HCD-RX55 - Panel, Sensor, and Switch Parts List

Ref. No. Part No. Description Remarks
— 83 —
Ref. No. Part No. Description Remarks
R626 1-247-847-11 CARBON 4.7K 5% 1/4W
R627 1-247-847-11 CARBON 4.7K 5% 1/4W
R628 1-247-847-11 CARBON 4.7K 5% 1/4W
R629 1-247-847-11 CARBON 4.7K 5% 1/4W
R630 1-247-847-11 CARBON 4.7K 5% 1/4W
R631 1-247-847-11 CARBON 4.7K 5% 1/4W
R632 1-247-847-11 CARBON 4.7K 5% 1/4W
R633 1-247-721-11 CARBON 4.7K 5% 1/4W F
R634 1-247-721-11 CARBON 4.7K 5% 1/4W F
R635 1-247-721-11 CARBON 4.7K 5% 1/4W F
R636 1-247-871-11 CARBON 47K 5% 1/4W
R637 1-247-839-11 CARBON 2.2K 5% 1/4W
R638 1-249-409-11 CARBON 220 5% 1/4W F
R639 1-247-702-11 CARBON 150 5% 1/4W F
R640 1-247-702-11 CARBON 150 5% 1/4W F
R641 1-247-702-11 CARBON 150 5% 1/4W F
R642 1-247-702-11 CARBON 150 5% 1/4W F
R643 1-247-702-11 CARBON 150 5% 1/4W F
R644 1-247-702-11 CARBON 150 5% 1/4W F
R645 1-246-451-15 CARBON 120 5% 1/4W
R646 1-246-451-15 CARBON 120 5% 1/4W
R647 1-249-407-11 CARBON 150 5% 1/4W F
R648 1-249-407-11 CARBON 150 5% 1/4W F
R649 1-249-407-11 CARBON 150 5% 1/4W F
R650 1-249-407-11 CARBON 150 5% 1/4W F
R651 1-249-407-11 CARBON 150 5% 1/4W F
R652 1-249-407-11 CARBON 150 5% 1/4W F
R653 1-247-847-11 CARBON 4.7K 5% 1/4W
R655 1-247-855-11 CARBON 10K 5% 1/4W
R661 1-247-714-11 CARBON 1.2K 5% 1/4W F
R662 1-249-420-11 CARBON 1.8K 5% 1/4W F
R663 1-247-718-11 CARBON 2.7K 5% 1/4W F
R664 1-247-720-11 CARBON 3.9K 5% 1/4W F
R665 1-249-427-11 CARBON 6.8K 5% 1/4W F
R666 1-249-431-11 CARBON 15K 5% 1/4W
R667 1-249-436-11 CARBON 39K 5% 1/4W
R668 1-249-418-11 CARBON 1.2K 5% 1/4W F
R669 1-249-420-11 CARBON 1.8K 5% 1/4W F
R670 1-247-718-11 CARBON 2.7K 5% 1/4W F
R671 1-249-418-11 CARBON 1.2K 5% 1/4W F
R672 1-249-420-11 CARBON 1.8K 5% 1/4W F
R673 1-249-418-11 CARBON 1.2K 5% 1/4W F
R674 1-249-420-11 CARBON 1.8K 5% 1/4W F
R675 1-247-718-11 CARBON 2.7K 5% 1/4W F
R676 1-249-424-11 CARBON 3.9K 5% 1/4W F
R677 1-249-427-11 CARBON 6.8K 5% 1/4W F
R678 1-249-431-11 CARBON 15K 5% 1/4W
R679 1-249-436-11 CARBON 39K 5% 1/4W
R690 1-247-855-11 CARBON 10K 5% 1/4W
< SWITCH >
S601 1-572-647-11 SWITCH, KEY BOARD (TUNER/BAND)
S602 1-572-647-11 SWITCH, KEY BOARD (CD)
S603 1-572-647-11 SWITCH, KEY BOARD (TAPE B)
S604 1-572-647-11 SWITCH, KEY BOARD (TAPE B)
S605 1-572-647-11 SWITCH, KEY BOARD (TAPE A)
S606 1-572-647-11 SWITCH, KEY BOARD (TAPE A)
S607 1-572-647-11 SWITCH, KEY BOARD (FUNCTION)
S608 1-572-647-11 SWITCH, KEY BOARD (EDIT/DIRECTION)
S609 1-572-647-11 SWITCH, KEY BOARD (REPEAT/MEMORY)
S610 1-572-647-11 SWITCH, KEY BOARD (STEREO/MONO)
S611 1-572-647-11 SWITCH, KEY BOARD (STOP)
S612 1-572-647-11 SWITCH, KEY BOARD (POWER)
S613 1-572-647-11 SWITCH, KEY BOARD (CLOCK/TIMER SET)
S614 1-572-647-11 SWITCH, KEY BOARD (TIMER SELECT)
S615 1-572-647-11 SWITCH, KEY BOARD (ENTER/NEXT)
S616 1-572-647-11 SWITCH, KEY BOARD (FILE SELECT)
S617 1-572-647-11 SWITCH, KEY BOARD (DBFB)
S618 1-572-647-11 SWITCH, KEY BOARD (DISPLAY/MONO)
S619 1-572-647-11 SWITCH, KEY BOARD (SURROUND)
S620 1-572-647-11 SWITCH, KEY BOARD (REC)
S621 1-572-647-11 SWITCH, KEY BOARD (PAUSE)
S622 1-572-647-11 SWITCH, KEY BOARD (CD SYNC)
S623 1-572-647-11 SWITCH, KEY BOARD (PLAY MODE)
S611A 1-572-647-11 SWITCH, KEY BOARD
< VIBRATOR >
X601 1-760-096-11 VIBRATOR, CRYSTAL
************************************************************
* 1-670-442-11 SENSOR BOARD
*************
< SENSOR >
RM601 8-749-013-84 IC SPS-447-1
************************************************************
* 1-670-797-11 SW (A) BOARD
*************
< SWITCH >
S04 1-771-169-11 SWITCH
************************************************************
* 1-670-798-11 SW (B) BOARD
*************
< SWITCH >
S03 1-771-169-11 SWITCH
************************************************************
* 1-670-799-11 SW (C) BOARD
*************
< SWITCH >
S02 1-571-300-31 SWITCH, ROTARY
************************************************************
* 1-670-800-11 SW (D) BOARD
************
< SWITCH >
S01 1-571-300-31 SWITCH, ROTARY
************************************************************
PANEL SENSOR SW (A) SW (B) SW (C) SW (D)
