Sony HCD-SHAKE77 - Overall Case Removal

HCD-SHAKE33/SHAKE77
10
Note: Follow the disassembly procedure in the numerical order given.
2-1. OVERALL CASE
Note: To disassemble the CASE, OVERALL, allen key
is required to unscrew the SCREW, TAPPING (HEX).
4 protector, rear R
8
5 seven screws
(+BVTP 3 u 8) (BLACK)
3 protector, rear L
1 four screws
(+BVTP 3 u 8) (BLACK)
2 two screws
(+BVTP 3 u 8) (BLACK)
6 three screws
(tapping (HEX))
9 case, overall
7 three screws
(tapping (HEX))
