Sony HCD-SHAKE77 - Unit Disassembly Guide

HCD-SHAKE33/SHAKE77
9
2-2. BACK PANEL SECTION
(Page 11)
2-3. LOADING PANEL ASSY
(Page 11)
2-4. CDM90-DVBU202//M
(Page 12)
2-5. FRONT PANEL SECTION
(Page 13)
2-6. MOTHERBOARD BOARD
(Page 13)
2-7. 4CH DAMP BOARD (SHAKE33), 6CH DAMP BOARD (SHAKE77)
(Page 14)
2-1. OVERALL CASE
(Page 10)
2-8. REGULATOR, SWITCHING (3H401W) (SHAKE33),
SWITCHING REGULATOR (SSN-GBR) (SHAKE77)
(Page 15)
2-9. SERVICE OPTICAL DEVICE,
WIRE (FLAT TYPE)
(Page 16)
SET
Note: Disassemble the unit in the order as shown below.
SECTION 2
DISASSEMBLY
