Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
73
HCD-VM330AV
BD CD LED CONTROL
R151 1-216-097-11 RES-CHIP 100K 5% 1/10W
R152 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R163 1-216-295-11 SHORT 0
R164 1-216-295-11 SHORT 0
R167 1-216-295-11 SHORT 0
R168 1-216-295-11 SHORT 0
R176 1-216-295-11 SHORT 0
R179 1-216-864-11 METAL CHIP 0 5% 1/16W
R201 1-216-085-00 RES-CHIP 33K 5% 1/10W
R202 1-216-073-00 RES-CHIP 10K 5% 1/10W
R203 1-216-097-11 RES-CHIP 100K 5% 1/10W
R204 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R205 1-216-049-11 RES-CHIP 1K 5% 1/10W
R206 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R207 1-216-121-11 RES-CHIP 1M 5% 1/10W
R212 1-216-033-00 METAL CHIP 220 5% 1/10W
R215 1-216-295-11 SHORT 0
R218 1-216-049-11 RES-CHIP 1K 5% 1/10W
R219 1-216-049-11 RES-CHIP 1K 5% 1/10W
R220 1-216-295-11 SHORT 0
R221 1-216-033-00 METAL CHIP 220 5% 1/10W
R222 1-216-033-00 METAL CHIP 220 5% 1/10W
R223 1-216-025-11 RES-CHIP 100 5% 1/10W
R224 1-216-033-00 METAL CHIP 220 5% 1/10W
R225 1-216-033-00 METAL CHIP 220 5% 1/10W
R226 1-216-025-11 RES-CHIP 100 5% 1/10W
R227 1-216-097-11 RES-CHIP 100K 5% 1/10W
R228 1-216-113-00 METAL CHIP 470K 5% 1/10W
R229 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R230 1-216-295-11 SHORT 0
R235 1-216-025-11 RES-CHIP 100 5% 1/10W
R236 1-216-025-11 RES-CHIP 100 5% 1/10W
R237 1-216-025-11 RES-CHIP 100 5% 1/10W
R239 1-216-035-00 METAL CHIP 270 5% 1/10W
R240 1-216-295-11 SHORT 0
< NETWORK RESISTOR >
RN201 1-233-576-11 RES, CHIP NETWORK 100
RN202 1-233-576-11 RES, CHIP NETWORK 100
< VARIABLE RESISTOR >
RV101 1-223-997-21 RES, CARBON ADJ VAR 47K
**************************************************************
1-680-795-21 CD LED BOARD
*************
< CONNECTOR >
CN803 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
< LED >
D781 8-719-058-64 LED SEL5823A-TP15 (DISC ILLUMINATION)
D782 8-719-058-03 LED SEL5423E-TP15 (DISC ILLUMINATION)
< RESISTOR >
R781 1-216-805-11 METAL CHIP 47 5% 1/16W
**************************************************************
A-4476-367-A CONTROL BOARD, COMPLETE
*************************
< CONNECTOR >
CN708 1-784-734-11 CONNECTOR, FFC 12P
< LED >
D708 8-719-052-06 LED SLR-342MGT32 (PRESET EQ)
D736 8-719-060-44 LED SLR-342VRT32 (I/1)
< TRANSISTOR >
Q718 8-729-038-67 TRANSISTOR KRC102S
< RESISTOR >
R725 1-216-813-11 METAL CHIP 220 5% 1/16W
R736 1-216-821-11 METAL CHIP 1K 5% 1/16W
R750 1-216-839-11 METAL CHIP 33K 5% 1/16W
R751 1-216-833-11 METAL CHIP 10K 5% 1/16W
R752 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R753 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R754 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R755 1-216-821-11 METAL CHIP 1K 5% 1/16W
R756 1-216-819-11 METAL CHIP 680 5% 1/16W
R760 1-216-839-11 METAL CHIP 33K 5% 1/16W
R761 1-216-833-11 METAL CHIP 10K 5% 1/16W
R762 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R763 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R764 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R765 1-216-821-11 METAL CHIP 1K 5% 1/16W
R766 1-216-819-11 METAL CHIP 680 5% 1/16W
R771 1-216-833-11 METAL CHIP 10K 5% 1/16W
R772 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R773 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R774 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R775 1-216-821-11 METAL CHIP 1K 5% 1/16W
R776 1-216-819-11 METAL CHIP 680 5% 1/16W
< ROTARY ENCODER >
RV701 1-473-392-11 ENCODER, ROTARY (VOLUME)
< SWITCH >
S700 1-762-196-21 SWITCH, TACT (I/1)
S750 1-762-196-21 SWITCH, TACT (SURROUND MODE)
S751 1-762-196-21 SWITCH, TACT (PRESET EQ)
S752 1-762-196-21 SWITCH, TACT (ENTER)
S753 1-762-196-21 SWITCH, TACT (– .)
S754 1-762-196-21 SWITCH, TACT (> +)
S755 1-762-196-21 SWITCH, TACT(X PAUSE)
S756 1-762-196-21 SWITCH, TACT (x)
S757 1-762-196-21 SWITCH, TACT (n N)
S760 1-762-196-21 SWITCH, TACT (TIMER SELECT)
S761 1-762-196-21 SWITCH, TACT (TIMER SET)
S762 1-762-196-21 SWITCH, TACT (m –)
S763 1-762-196-21 SWITCH, TACT (M +)
S764 1-762-196-21 SWITCH, TACT (TUNER/BAND)
S765 1-762-196-21 SWITCH, TACT (CD)
