Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
74
HCD-VM330AV
CONTROL D SENSOR (IN) D SENSOR (OUT) DISPLAY
S766 1-762-196-21 SWITCH, TACT (TAPE A/B)
S767 1-762-196-21 SWITCH, TACT (5.1CH/VIDEO (MD))
S770 1-762-196-21 SWITCH, TACT (DISPLAY)
S771 1-762-196-21 SWITCH, TACT (PLAY MODE)
S772 1-762-196-21 SWITCH, TACT (REPEAT STEREO/MONO)
S773 1-762-196-21 SWITCH, TACT (CD SYNCRO)
S774 1-762-196-21 SWITCH, TACT (REC PAUSE/START)
S775 1-762-196-21 SWITCH, TACT (CLEAR)
S776 1-762-196-21 SWITCH, TACT (DIRECTION)
S777 1-762-196-21 SWITCH, TACT (MENU)
**************************************************************
1-680-799-21 D SENSOR (IN) BOARD
*******************
* 4-976-474-01 HOLDER (P-T)
< PHOTO TRANSISTOR >
Q841 8-729-921-53 PHOTO TRANSISTOR PT483F1
**************************************************************
1-680-800-21 D SENSOR (OUT) BOARD
*********************
* 4-976-473-01 HOLDER (LED-S)
< LED >
D841 8-719-055-84 LED GL528VS1 (DISC IN DETECT SENSOR)
< RESISTOR >
R841 1-216-819-11 METAL CHIP 680 5% 1/16W
**************************************************************
A-4476-368-A DISPLAY BOARD, COMPLETE
************************
4-232-752-01 HOLDER, FL
4-232-753-01 DIAL, JOG
< CAPACITOR >
C701 1-104-665-11 ELECT 100uF 20% 10V
C702 1-104-665-11 ELECT 100uF 20% 10V
C703 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C704 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C706 1-126-963-11 ELECT 4.7uF 20% 50V
C708 1-104-665-11 ELECT 100uF 20% 10V
C710 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C711 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C712 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C713 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C714 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C715 1-126-960-11 ELECT 1uF 20% 50V
C717 1-126-960-11 ELECT 1uF 20% 50V
C740 1-126-964-11 ELECT 10uF 20% 50V
C741 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C742 1-126-964-11 ELECT 10uF 20% 50V
C743 1-126-964-11 ELECT 10uF 20% 50V
C744 1-104-665-11 ELECT 100uF 20% 10V
C745 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN701 1-784-739-11 CONNECTOR, FFC 17P
CN704 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
* CN705 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN707 1-784-734-11 CONNECTOR, FFC 12P
< DIODE >
D701 8-719-063-79 DIODE 1N4002B
D702 8-719-063-79 DIODE 1N4002B
D703 8-719-052-06 LED SLR-342MGT32 (LINK)
D704 8-719-052-06 LED SLR-342MGT32 (REAR)
D705 8-719-052-06 LED SLR-342MGT32 (FRONT)
D706 8-719-052-06 LED SLR-342MGT32 (PRO LOGIC)
D707 8-719-052-06 LED SLR-342MGT32 (SURROUND)
D710 8-719-991-33 DIODE 1SS133T-77
< FLUORESCENT INDICATOR TUBE >
FL701 1-518-748-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC701 6-800-337-01 IC MB90M407APF-G-108-BND
IC703 8-759-495-25 IC BA3833FP-E2
< SHORT >
JR701 1-216-864-11 SHORT 0
JR702 1-216-864-11 SHORT 0
JR703 1-216-864-11 SHORT 0
JR704 1-216-864-11 SHORT 0
JR705 1-216-864-11 SHORT 0
JR706 1-216-864-11 SHORT 0
JR707 1-216-864-11 SHORT 0
< TRANSISTOR >
Q702 8-729-036-89 TRANSISTOR KTC3198GR-A
Q703 8-729-036-89 TRANSISTOR KTC3198GR-A
Q704 8-729-038-67 TRANSISTOR KRC102S
Q705 8-729-038-67 TRANSISTOR KRC102S
Q713 8-729-038-67 TRANSISTOR KRC102S
Q714 8-729-038-67 TRANSISTOR KRC102S
Q715 8-729-038-67 TRANSISTOR KRC102S
Q716 8-729-038-67 TRANSISTOR KRC102S
Q717 8-729-038-67 TRANSISTOR KRC102S
Q721 8-729-036-89 TRANSISTOR KTC3198GR-A
Q722 8-729-036-89 TRANSISTOR KTC3198GR-A
Q723 8-729-036-89 TRANSISTOR KTC3198GR-A
< RESISTOR >
R701 1-216-821-11 METAL CHIP 1K 5% 1/16W
R702 1-216-821-11 METAL CHIP 1K 5% 1/16W
R703 1-216-821-11 METAL CHIP 1K 5% 1/16W
R704 1-216-821-11 METAL CHIP 1K 5% 1/16W
R705 1-216-845-11 METAL CHIP 100K 5% 1/16W
R706 1-216-809-11 METAL CHIP 100 5% 1/16W
R707 1-216-821-11 METAL CHIP 1K 5% 1/16W
R708 1-216-849-11 METAL CHIP 220K 5% 1/16W
R709 1-216-845-11 METAL CHIP 100K 5% 1/16W
R710 1-216-845-11 METAL CHIP 100K 5% 1/16W
