Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
75
HCD-VM330AV
R711 1-216-845-11 METAL CHIP 100K 5% 1/16W
R712 1-216-845-11 METAL CHIP 100K 5% 1/16W
R713 1-216-833-11 METAL CHIP 10K 5% 1/16W
R714 1-216-819-11 METAL CHIP 680 5% 1/16W
R715 1-216-813-11 METAL CHIP 220 5% 1/16W
R716 1-216-805-11 METAL CHIP 47 5% 1/16W
R717 1-216-813-11 METAL CHIP 220 5% 1/16W
R718 1-216-845-11 METAL CHIP 100K 5% 1/16W
R719 1-216-845-11 METAL CHIP 100K 5% 1/16W
R720 1-216-833-11 METAL CHIP 10K 5% 1/16W
R721 1-216-813-11 METAL CHIP 220 5% 1/16W
R722 1-216-813-11 METAL CHIP 220 5% 1/16W
R723 1-216-833-11 METAL CHIP 10K 5% 1/16W
R724 1-216-845-11 METAL CHIP 100K 5% 1/16W
R727 1-216-813-11 METAL CHIP 220 5% 1/16W
R728 1-216-845-11 METAL CHIP 100K 5% 1/16W
R729 1-216-845-11 METAL CHIP 100K 5% 1/16W
R730 1-216-845-11 METAL CHIP 100K 5% 1/16W
R731 1-216-845-11 METAL CHIP 100K 5% 1/16W
R732 1-216-841-11 METAL CHIP 47K 5% 1/16W
R733 1-216-841-11 METAL CHIP 47K 5% 1/16W
R734 1-216-841-11 METAL CHIP 47K 5% 1/16W
R735 1-216-845-11 METAL CHIP 100K 5% 1/16W
R737 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R738 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R739 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R740 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R742 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R743 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R744 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R745 1-216-821-11 METAL CHIP 1K 5% 1/16W
R746 1-216-833-11 METAL CHIP 10K 5% 1/16W
R747 1-216-845-11 METAL CHIP 100K 5% 1/16W
R748 1-216-833-11 METAL CHIP 10K 5% 1/16W
R749 1-216-845-11 METAL CHIP 100K 5% 1/16W
R757 1-216-833-11 METAL CHIP 10K 5% 1/16W
R758 1-216-833-11 METAL CHIP 10K 5% 1/16W
R782 1-216-845-11 METAL CHIP 100K 5% 1/16W
R783 1-216-845-11 METAL CHIP 100K 5% 1/16W
R784 1-216-845-11 METAL CHIP 100K 5% 1/16W
R785 1-216-845-11 METAL CHIP 100K 5% 1/16W
< ROTARY ENCODER >
RV702 1-476-597-11 ENCODER (ROTARY TYPE) (DISC ACCESS)
< SWITCH >
S741 1-762-196-21 SWITCH, TACT (LINK)
S742 1-762-196-21 SWITCH, TACT (REAR)
S743 1-762-196-21 SWITCH, TACT (FRONT)
S744 1-762-196-21 SWITCH, TACT (PRO LOGIC)
S745 1-762-196-21 SWITCH, TACT (SURROUND)
< VIBRATOR >
X701 1-577-082-11 VIBRATOR, CERAMIC (4MHz)
**************************************************************
1-680-794-21 DOOR LED BOARD
***************
< LED >
D791 8-719-072-76 LED SEL5E23C-TP15
(CD LID ILLUMINATION)
< RESISTOR >
R791 1-216-799-11 METAL CHIP 15 5% 1/16W
**************************************************************
1-683-049-11 FUSE BOARD
***********
1-533-233-31 HOLDER, FUSE
< CONNECTOR >
CN901 1-564-521-11 PLUG, CONNECTOR 6P
< FUSE >
0 F905 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) (T3.15AL/250V)
0 F906 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) (T3.15AL/250V)
0 F907 1-533-472-11 FUSE, GLASS TUBE (DIA. 5) (T5AL/250V)
0 F908 1-533-472-11 FUSE, GLASS TUBE (DIA. 5) (T5AL/250V)
**************************************************************
1-680-808-11 GAME LINK BOARD
****************
< CAPACITOR >
C705 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< JACK >
J701 1-815-646-11 JACK, PIN 3P (VIDEO IN, AUDIO IN)
< SWITCH >
S701 1-762-196-21 SWITCH, TACT (GAME)
**************************************************************
1-680-796-21 H/P BOARD
**********
< JACK >
J503 1-815-629-11 JACK (SMALL TYPE) (DIA.3.5) (PHONE)
J801 1-815-575-11 CONNECTOR, DIN 6P (KEYBOARD INPUT)
< COIL >
L801 1-410-517-11 INDUCTOR 47uH
**************************************************************
1-680-797-21 L.T MOTOR BOARD
****************
**************************************************************
DISPLAY DOOR LED FUSE GAME LINK H/P L.T MOTOR
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
