Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
81
HCD-VM330AV
< IC >
IC501 8-749-016-95 IC STK402-100S
IC602 8-749-017-97 IC STK402-240
< TERMINAL >
J501 1-694-805-11 TERMINAL BOARD (FRONT SPEAKER,
SURROUND SPEAKER REAR (L))
J502 1-694-785-11 TERMINAL BOARD
(SURROUND SPEAKER REAR (R)/CENTER)
< TRANSISTOR >
Q501 8-729-036-77 TRANSISTOR KRC107M-AT
Q502 8-729-036-77 TRANSISTOR KRC107M-AT
Q503 8-729-037-34 TRANSISTOR KRA107M-AT
Q504 8-729-037-34 TRANSISTOR KRA107M-AT
Q505 8-729-036-89 TRANSISTOR KTC3198GR-A
Q506 8-729-036-89 TRANSISTOR KTC3198GR-A
Q507 8-729-036-89 TRANSISTOR KTC3198GR-A
Q508 8-729-036-77 TRANSISTOR KRC107M-AT
Q509 8-729-036-77 TRANSISTOR KRC107M-AT
Q510 8-729-036-77 TRANSISTOR KRC107M-AT
Q513 8-729-036-89 TRANSISTOR KTC3198GR-A
Q514 8-729-037-02 TRANSISTOR KTA1266Y-AT
Q515 8-729-036-89 TRANSISTOR KTC3198GR-A
Q516 8-729-037-34 TRANSISTOR KRA107M-AT
Q517 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q518 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q519 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q520 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q521 8-729-038-67 TRANSISTOR KRC102S
Q522 8-759-068-54 TRANSISTOR KRA102S
Q523 8-759-068-54 TRANSISTOR KRA102S
Q524 8-729-038-67 TRANSISTOR KRC102S
Q601 8-729-036-89 TRANSISTOR KTC3198GR-A
Q602 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q603 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q604 8-729-036-89 TRANSISTOR KTC3198GR-A
Q605 8-729-036-89 TRANSISTOR KTC3198GR-A
Q606 8-729-036-89 TRANSISTOR KTC3198GR-A
< RESISTOR >
R501 1-216-837-11 METAL CHIP 22K 5% 1/16W
R502 1-216-841-11 METAL CHIP 47K 5% 1/16W
R504 1-216-821-11 METAL CHIP 1K 5% 1/16W
R505 1-216-837-11 METAL CHIP 22K 5% 1/16W
0 R506 1-215-891-11 METAL OXIDE 680 5% 2W F
R507 1-216-821-11 METAL CHIP 1K 5% 1/16W
R508 1-249-417-11 CARBON 1K 5% 1/4W
R509 1-249-417-11 CARBON 1K 5% 1/4W
0 R510 1-215-891-11 METAL OXIDE 680 5% 2W F
R512 1-216-841-11 METAL CHIP 47K 5% 1/16W
R513 1-216-841-11 METAL CHIP 47K 5% 1/16W
R514 1-216-841-11 METAL CHIP 47K 5% 1/16W
R516 1-216-841-11 METAL CHIP 47K 5% 1/16W
R518 1-216-841-11 METAL CHIP 47K 5% 1/16W
R519 1-216-841-11 METAL CHIP 47K 5% 1/16W
R520 1-216-841-11 METAL CHIP 47K 5% 1/16W
R522 1-216-841-11 METAL CHIP 47K 5% 1/16W
0 R523 1-215-892-11 METAL OXIDE 1K 5% 2W F
R524 1-249-401-11 CARBON 47 5% 1/4W
R525 1-249-401-11 CARBON 47 5% 1/4W
R526 1-249-401-11 CARBON 47 5% 1/4W
R527 1-249-401-11 CARBON 47 5% 1/4W
0 R528 1-215-892-11 METAL OXIDE 1K 5% 2W F
R529 1-216-841-11 METAL CHIP 47K 5% 1/16W
R531 1-216-837-11 METAL CHIP 22K 5% 1/16W
R532 1-216-837-11 METAL CHIP 22K 5% 1/16W
R533 1-216-837-11 METAL CHIP 22K 5% 1/16W
R534 1-216-837-11 METAL CHIP 22K 5% 1/16W
R535 1-216-845-11 METAL CHIP 100K 5% 1/16W
R536 1-216-845-11 METAL CHIP 100K 5% 1/16W
0 R537 1-215-892-11 METAL OXIDE 1K 5% 2W F
R539 1-216-845-11 METAL CHIP 100K 5% 1/16W
R540 1-216-841-11 METAL CHIP 47K 5% 1/16W
0 R542 1-234-499-21 ENCAPSULATED COMPONENT 0.22 5W
0 R544 1-234-499-21 ENCAPSULATED COMPONENT 0.22 5W
R545 1-216-821-11 METAL CHIP 1K 5% 1/16W
R546 1-216-835-11 METAL CHIP 15K 5% 1/16W
R547 1-216-835-11 METAL CHIP 15K 5% 1/16W
R548 1-216-821-11 METAL CHIP 1K 5% 1/16W
0 R551 1-212-881-11 FUSIBLE 100 5% 1/4W F
R552 1-216-841-11 METAL CHIP 47K 5% 1/16W
R553 1-216-841-11 METAL CHIP 47K 5% 1/16W
0 R554 1-212-881-11 FUSIBLE 100 5% 1/4W F
R555 1-249-425-11 CARBON 4.7K 5% 1/4W
R557 1-216-841-11 METAL CHIP 47K 5% 1/16W
R558 1-216-821-11 METAL CHIP 1K 5% 1/16W
R559 1-216-821-11 METAL CHIP 1K 5% 1/16W
R560 1-249-429-11 CARBON 10K 5% 1/4W
R561 1-216-841-11 METAL CHIP 47K 5% 1/16W
R562 1-216-841-11 METAL CHIP 47K 5% 1/16W
R563 1-216-841-11 METAL CHIP 47K 5% 1/16W
R564 1-216-821-11 METAL CHIP 1K 5% 1/16W
R565 1-216-821-11 METAL CHIP 1K 5% 1/16W
R601 1-249-417-11 CARBON 1K 5% 1/4W
R602 1-216-833-11 METAL CHIP 10K 5% 1/16W
R603 1-216-833-11 METAL CHIP 10K 5% 1/16W
R604 1-249-429-11 CARBON 10K 5% 1/4W
R605 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R606 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R607 1-216-821-11 METAL CHIP 1K 5% 1/16W
R608 1-216-821-11 METAL CHIP 1K 5% 1/16W
R609 1-216-841-11 METAL CHIP 47K 5% 1/16W
R610 1-216-841-11 METAL CHIP 47K 5% 1/16W
R611 1-249-417-11 CARBON 1K 5% 1/4W
R612 1-216-833-11 METAL CHIP 10K 5% 1/16W
R613 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R614 1-216-833-11 METAL CHIP 10K 5% 1/16W
0 R615 1-212-881-11 FUSIBLE 100 5% 1/4W F
R616 1-216-841-11 METAL CHIP 47K 5% 1/16W
R617 1-216-841-11 METAL CHIP 47K 5% 1/16W
0 R618 1-212-881-11 FUSIBLE 100 5% 1/4W F
R619 1-216-821-11 METAL CHIP 1K 5% 1/16W
R620 1-216-835-11 METAL CHIP 15K 5% 1/16W
R621 1-216-835-11 METAL CHIP 15K 5% 1/16W
MAIN AMP
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
