Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
82
HCD-VM330AV
R622 1-216-821-11 METAL CHIP 1K 5% 1/16W
0R623 1-233-352-41 ENCAPSULATED COMPONENT 0.22 5W
R624 1-216-833-11 METAL CHIP 10K 5% 1/16W
R625 1-216-821-11 METAL CHIP 1K 5% 1/16W
0R626 1-233-352-41 ENCAPSULATED COMPONENT 0.22 5W
R627 1-216-845-11 METAL CHIP 100K 5% 1/16W
R628 1-216-845-11 METAL CHIP 100K 5% 1/16W
R629 1-249-401-11 CARBON 47 5% 1/4W
R630 1-249-401-11 CARBON 47 5% 1/4W
R631 1-249-401-11 CARBON 47 5% 1/4W
R632 1-249-401-11 CARBON 47 5% 1/4W
R634 1-216-821-11 METAL CHIP 1K 5% 1/16W
R635 1-216-841-11 METAL CHIP 47K 5% 1/16W
R636 1-216-821-11 METAL CHIP 1K 5% 1/16W
R638 1-216-841-11 METAL CHIP 47K 5% 1/16W
R639 1-216-835-11 METAL CHIP 15K 5% 1/16W
R640 1-216-821-11 METAL CHIP 1K 5% 1/16W
0R642 1-233-352-41 ENCAPSULATED COMPONENT 0.22 5W
R643 1-216-845-11 METAL CHIP 100K 5% 1/16W
R644 1-249-401-11 CARBON 47 5% 1/4W
R645 1-249-401-11 CARBON 47 5% 1/4W
< RELAY >
RY501 1-515-920-11 RELAY (24V)
RY502 1-515-920-11 RELAY (24V)
RY503 1-515-920-11 RELAY (24V)
**************************************************************
1-680-803-31 POWER BOARD
*************
1-533-233-31 HOLDER, FUSE
1-535-416-00 TERMINAL
< CAPACITOR >
C901 1-126-968-11 ELECT 100uF 20% 50V
C902 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C903 1-126-767-11 ELECT 1000uF 20% 16V
C911 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C912 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C913 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C914 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
0C991 1-113-925-11 CERAMIC 0.01uF 20% 250V
< DIODE >
D901 8-719-063-79 DIODE 1N4002B
D902 8-719-063-79 DIODE 1N4002B
D911 8-719-991-33 DIODE 1SS133T-77
D912 8-719-991-33 DIODE 1SS133T-77
D913 8-719-991-33 DIODE 1SS133T-77
D914 8-719-991-33 DIODE 1SS133T-77
< FUSE >
0F901 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) (T3.15AL/250V)
0F902 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) (T3.15AL/250V)
0F902 1-533-467-11 FUSE, GLASS TUBE (DIA. 5) (T1.6AL/250V)
< LINE FILTER >
0 LF901 1-402-663-11 TRANSFORMER, LINE FILTER (LFT)
< TRANSISTOR >
Q901 8-729-036-77 TRANSISTOR KRC107M-AT
< RESISTOR >
0 R901 1-212-881-11 FUSIBLE 100 5% 1/4W
< RELAY >
0 RY901 1-755-332-11 RELAY
< TRANSFORMER >
0 T901 1-437-290-11 TRANSFORMER, POWER
0 T902 1-437-294-11 TRANSFORMER, POWER
**************************************************************
1-680-809-11 RMC BOARD
**********
< IC >
IC702 8-759-827-70 IC NJL64H400A-1
**************************************************************
A-4476-373-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C401 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C402 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C403 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C404 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C405 1-126-923-11 ELECT 220uF 20% 10V
C406 1-130-486-00 MYLAR 0.018uF 10% 50V
C408 1-126-947-11 ELECT 47uF 20% 10V
C409 1-126-963-11 ELECT 4.7uF 20% 50V
C410 1-126-963-11 ELECT 4.7uF 20% 50V
C411 1-126-947-11 ELECT 47uF 20% 10V
C412 1-126-961-11 ELECT 2.2uF 20% 50V
C414 1-126-947-11 ELECT 47uF 20% 10V
C415 1-126-947-11 ELECT 47uF 20% 10V
C416 1-126-963-11 ELECT 4.7uF 20% 50V
C417 1-126-963-11 ELECT 4.7uF 20% 50V
C418 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C419 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C420 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C421 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C422 1-126-960-11 ELECT 1uF 20% 50V
C423 1-126-960-11 ELECT 1uF 20% 50V
C424 1-126-960-11 ELECT 1uF 20% 50V
C425 1-126-933-11 ELECT 100uF 20% 16V
C426 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C427 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C428 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C429 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C430 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C431 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
