Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
83
HCD-VM330AV
C432 1-130-483-00 MYLAR 0.01uF 5% 50V
C433 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C434 1-126-947-11 ELECT 47uF 20% 10V
C435 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C436 1-130-481-00 MYLAR 0.0068uF 5% 50V
C437 1-126-923-11 ELECT 220uF 20% 10V
C438 1-130-486-00 MYLAR 0.018uF 10% 50V
C439 1-126-933-11 ELECT 100uF 20% 16V
C441 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C442 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C443 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C444 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN401 1-695-371-31 CONNECTOR, FFC 10P
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
< IC >
IC401 8-759-242-58 IC TA8189N
IC402 8-759-143-54 IC uPC1330HA
< TRANSISTOR >
Q401 8-729-212-02 TRANSISTOR KTC3203Y-AT
Q402 8-729-037-02 TRANSISTOR KTA1266Y-AT
Q403 8-729-038-67 TRANSISTOR KRC102S
Q404 8-729-036-89 TRANSISTOR KTC3198GR-A
Q405 8-729-036-89 TRANSISTOR KTC3198GR-A
< RESISTOR >
R401 1-216-821-11 METAL CHIP 1K 5% 1/16W
R402 1-216-821-11 METAL CHIP 1K 5% 1/16W
R403 1-216-821-11 METAL CHIP 1K 5% 1/16W
R404 1-216-821-11 METAL CHIP 1K 5% 1/16W
R405 1-216-809-11 METAL CHIP 100 5% 1/16W
R406 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R407 1-216-848-11 METAL CHIP 180K 5% 1/16W
R408 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R409 1-216-809-11 METAL CHIP 100 5% 1/16W
R410 1-216-848-11 METAL CHIP 180K 5% 1/16W
R411 1-216-845-11 METAL CHIP 100K 5% 1/16W
R412 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R413 1-216-848-11 METAL CHIP 180K 5% 1/16W
R414 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R415 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R416 1-216-833-11 METAL CHIP 10K 5% 1/16W
R417 1-216-805-11 METAL CHIP 47 5% 1/16W
R418 1-216-845-11 METAL CHIP 100K 5% 1/16W
R419 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R420 1-216-848-11 METAL CHIP 180K 5% 1/16W
R421 1-216-857-11 METAL CHIP 1M 5% 1/16W
R422 1-216-833-11 METAL CHIP 10K 5% 1/16W
R423 1-216-857-11 METAL CHIP 1M 5% 1/16W
R424 1-216-801-11 METAL CHIP 22 5% 1/16W
R425 1-216-841-11 METAL CHIP 47K 5% 1/16W
R426 1-216-845-11 METAL CHIP 100K 5% 1/16W
R427 1-216-809-11 METAL CHIP 100 5% 1/16W
R428 1-216-835-11 METAL CHIP 15K 5% 1/16W
R429 1-216-835-11 METAL CHIP 15K 5% 1/16W
R430 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R431 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R432 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R433 1-216-805-11 METAL CHIP 47 5% 1/16W
R434 1-216-803-11 METAL CHIP 33 5% 1/16W
R435 1-216-833-11 METAL CHIP 10K 5% 1/16W
R436 1-216-797-11 METAL CHIP 10 5% 1/16W
R437 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R438 1-216-841-11 METAL CHIP 47K 5% 1/16W
R439 1-216-837-11 METAL CHIP 22K 5% 1/16W
R441 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R443 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R444 1-216-819-11 METAL CHIP 680 5% 1/16W
R445 1-216-819-11 METAL CHIP 680 5% 1/16W
< TRANSFORMER/COIL >
T401 1-433-372-11 TRANSFORMER, BIAS OSCILLATION
T402 1-419-080-11 COIL
T403 1-419-080-11 COIL
**************************************************************
1-680-817-21 T SENSOR BOARD
***************
< PHOTO INTERRUPTER >
IC11 8-749-924-18 PHOTO INTERRUPTER RPI-1391
IC12 8-749-924-18 PHOTO INTERRUPTER RPI-1391
IC13 8-749-924-18 PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R891 1-216-820-11 METAL CHIP 820 5% 1/16W
R892 1-216-820-11 METAL CHIP 820 5% 1/16W
R893 1-216-820-11 METAL CHIP 820 5% 1/16W
**************************************************************
A-4727-004-A VIDEO BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-164-670-11 CERAMIC CHIP 1200PF 5% 16V
C103 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-164-670-11 CERAMIC CHIP 1200PF 5% 16V
C203 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C304 1-164-388-11 CERAMIC CHIP 270PF 5% 50V
C305 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C306 1-164-388-11 CERAMIC CHIP 270PF 5% 50V
C307 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C308 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C309 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C310 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C311 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C312 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C313 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
TC T SENSOR VIDEO
