– 122 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DOOR SW
S679 1-554-303-21 SWITCH, TACTILE (‚)
S681 1-554-303-21 SWITCH, TACTILE (fl)
S682 1-554-303-21 SWITCH, TACTILE (π)
S683 1-554-303-21 SWITCH, TACTILE (DISC SKIP)
S702 1-473-534-11 ENCODER, ROTARY (JOG = AMS +)
**************************************************************
* 1-672-191-12 DOOR SW BOARD
*************
< CAPACITOR >
C691 1-162-306-11 CERAMIC 0.01uF 20% 16V
< SWITCH >
S691 1-771-057-11 SWITCH, PUSH (1 KEY)(§ OPEN)
**************************************************************
* 1-672-190-12 FRONT INPUT BOARD
*****************
< CAPACITOR >
C801 1-162-294-31 CERAMIC 0.001uF 10% 50V
C802 1-162-294-31 CERAMIC 0.001uF 10% 50V
C811 1-162-282-31 CERAMIC 100PF 10% 50V
C812 1-164-159-21 CERAMIC 0.1uF 50V
C813 1-126-960-11 ELECT 1uF 20% 50V
< FLUORESCENT INDICATOR >
FL803 1-424-228-11 FILTER, NOISE
< JACK >
J804 1-764-592-41 JACK 3P (AUDIO L/R, VIDEO)
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-417-11 CARBON 1K 5% 1/4W F
R804 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-247-804-11 CARBON 75 5% 1/4W
**************************************************************
A-4417-554-A JACK BOARD, COMPLETE
********************
< CAPACITOR >
C803 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-957-11 ELECT 0.22uF 20% 50V
C807 1-162-294-31 CERAMIC 0.001uF 10% 50V
C808 1-162-294-31 CERAMIC 0.001uF 10% 50V
C809 1-164-159-21 CERAMIC 0.1uF 50V
C810 1-164-159-21 CERAMIC 0.1uF 50V
C856 1-162-294-31 CERAMIC 0.001uF 10% 50V
C857 1-162-286-21 CERAMIC 220PF 10% 50V
C858 1-126-964-11 ELECT 10uF 20% 50V
CD-R
C859 1-126-961-11 ELECT 2.2uF 20% 50V
C860 1-162-215-31 CERAMIC 47PF 5% 50V
C861 1-162-282-31 CERAMIC 100PF 10% 50V
C862 1-126-961-11 ELECT 2.2uF 20% 50V
C863 1-126-960-11 ELECT 1uF 20% 50V
C864 1-126-964-11 ELECT 10uF 20% 50V
C865 1-126-960-11 ELECT 1uF 20% 50V
C866 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C867 1-162-294-31 CERAMIC 0.001uF 10% 50V
C868 1-136-495-11 FILM 0.068uF 5% 50V
C869 1-126-959-11 ELECT 0.47uF 20% 50V
C870 1-126-959-11 ELECT 0.47uF 20% 50V
C871 1-126-967-11 ELECT 47uF 20% 50V
C872 1-162-306-11 CERAMIC 0.01uF 20% 16V
C873 1-104-664-11 ELECT 47uF 20% 25V
C874 1-136-495-11 FILM 0.068uF 5% 50V
C875 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C876 1-162-294-31 CERAMIC 0.001uF 10% 50V
C877 1-136-167-00 FILM 0.15uF 5% 50V
C878 1-126-960-11 ELECT 1uF 20% 50V
C879 1-161-494-00 CERAMIC 0.022uF 25V
C880 1-126-961-11 ELECT 2.2uF 20% 50V
C882 1-162-290-31 CERAMIC 470PF 10% 50V
C883 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN802 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
< DIODE >
D851 8-719-200-82 DIODE 11ES2
D852 8-719-200-82 DIODE 11ES2
D853 8-719-200-82 DIODE 11ES2
< GROUND TERMINAL >
* EPT802 1-537-738-21 TERMINAL, EARTH
< FLUORESCENT INDICATOR >
FL801 1-424-228-11 FILTER, NOISE
FL802 1-424-228-11 FILTER, NOISE
< IC >
IC850 8-759-634-50 IC M5218AL
IC851 8-759-450-96 IC M65850P
< JACK >
J801 1-770-226-11 JACK (LARGE TYPE)(MIC 1)
J802 1-770-226-11 JACK (LARGE TYPE)(MIC 2)
J803 1-770-226-11 JACK (LARGE TYPE)(PHONES)
< COIL >
L851 1-410-521-11 INDUCTOR 100uH
< RESISTOR >
R806 1-249-429-11 CARBON 10K 5% 1/4W
R807 1-249-429-11 CARBON 10K 5% 1/4W
R808 1-249-417-11 CARBON 1K 5% 1/4W F
JACK
FRONT INPUT
