– 123 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R809 1-249-417-11 CARBON 1K 5% 1/4W F
R810 1-247-807-31 CARBON 100 5% 1/4W
R850 1-247-807-31 CARBON 100 5% 1/4W
R852 1-249-441-11 CARBON 100K 5% 1/4W
R853 1-249-417-11 CARBON 1K 5% 1/4W F
R854 1-249-437-11 CARBON 47K 5% 1/4W
R855 1-249-429-11 CARBON 10K 5% 1/4W
R856 1-247-889-00 CARBON 270K 5% 1/4W
R857 1-247-807-31 CARBON 100 5% 1/4W
R858 1-247-863-91 CARBON 22K 5% 1/4W
R859 1-247-863-91 CARBON 22K 5% 1/4W
R860 1-247-863-91 CARBON 22K 5% 1/4W
R861 1-247-881-00 CARBON 120K 5% 1/4W
R862 1-247-863-91 CARBON 22K 5% 1/4W
R863 1-247-863-91 CARBON 22K 5% 1/4W
R864 1-247-863-91 CARBON 22K 5% 1/4W
R865 1-249-437-11 CARBON 47K 5% 1/4W
R866 1-249-431-11 CARBON 15K 5% 1/4W
R867 1-249-431-11 CARBON 15K 5% 1/4W
< VARIABLE RESISTOR >
RV850 1-225-587-11 RES, VAR, CARBON 50K (MIC VOL)
RV851 1-225-587-11 RES, VAR, CARBON 50K (ECHO LEVEL)
**************************************************************
A-2007-800-A LEAF SW BOARD, COMPLETE
***********************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-784-459-11 CONNECTOR, FFC/FPC 17P
< DIODE >
D1001 8-719-991-33 DIODE 1SS133T-77
D1002 8-719-991-33 DIODE 1SS133T-77
< CABLE HOLDER >
* DM1001 1-784-581-11 HOLDER, CABLE (2.5MM PITCH) 4P
< IC >
IC1001 8-749-014-38 IC PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 IC PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA
Q1001 8-729-900-65 TRANSISTOR DTA144ES
< RESISTOR >
R907 1-249-441-11 CARBON 100K 5% 1/4W
R1001 1-247-815-91 CARBON 220 5% 1/4W
R1002 1-247-815-91 CARBON 220 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-91 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-856-00 CARBON 11K 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY)(A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY)(B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (A HALF)
S1004 1-771-205-11 SWITCH, LEAF (A 120/70)
S1005 1-771-205-11 SWITCH, LEAF (REC A)
S1006 1-771-333-11 SWITCH, LEAF (B HALF)
S1008 1-771-205-11 SWITCH, LEAF (B 120/70)
S1009 1-771-205-11 SWITCH, LEAF (REC B)
**************************************************************
* 1-659-059-13 LED (CD) BOARD
**************
< DIODE >
D201 8-719-032-98 DIODE SEL5820A (DISC NO.)
< TRANSISTOR >
Q201 8-729-119-78 TRANSISTOR 2SC403SP-51
< RESISTOR >
R201 1-247-863-91 CARBON 22K 5% 1/4W
R202 1-249-411-11 CARBON 330 5% 1/4W
R203 1-249-437-11 CARBON 47K 5% 1/4W
**************************************************************
* 1-672-195-11 LED (PANEL) BOARD
*****************
< DIODE >
D671 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
D672 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
D673 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
D674 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
D675 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
< RESISTOR >
R600 1-249-410-11 CARBON 270 5% 1/4W F
**************************************************************
LED (CD) LED (PANEL)LEAF SWJACK
