Sony HCD-VX222 - PRINTED WIRING BOARD - VIDEO CD SECTION

4040
HCD-VX222
6-19. PRINTED WIRING BOARD – VIDEO CD SECTION –
• See page 21 for Circuit Boards Location.
2
1
22
23
TO
PANEL
BOARD
(Page 36)
321
13
13
13
13
H
G
E
12
A
B
C
D
E
F
G
345678910
(Page 26)
(Page 28)
E C B E C B
E C B
Ref. No. Location
D501 C-2
IC101 F-4
IC301 B-9
IC302 B-9
IC303 B-4
IC304 B-7
IC501 D-8
IC502 E-9
IC504 E-4
IC505 C-3
IC506 D-7
IC507 C-4
IC509 E-5
Q501 C-3
Q502 C-2
Q531 C-9
• Semiconductor
Location
