56
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-VX222
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
EA : Saudi Arabia model
SP : Singapore model
TH : Thai model
TW : Taiwan model
IA : Indonesian model
E91 : 220VAC model
BD
When indicating parts by reference
number, please include the board
name.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
1-675-911-14 ADDRESS SENSOR BOARD
*******************
< CAPACITOR >
C712 1-164-159-21 CERAMIC 0.1uF 50V
< IC >
IC711 8-749-014-38 PHOTO INTERRUPTER SG-264
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-249-409-11 CARBON 220 5% 1/4W F
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY) (UP/DOWN)
******************************************************
A-4725-001-A BD BOARD, COMPLETE (E91,TH)
A-4725-003-A BD BOARD, COMPLETE (E,EA,IA,SP,TW)
************************
< CAPACITOR >
C101 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C102 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C103 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C105 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C106 1-164-346-11 CERAMIC CHIP 1uF 16V
C107 1-164-346-11 CERAMIC CHIP 1uF 16V
C108 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C109 1-163-145-00 CERAMIC CHIP 0.0015uF 5% 50V
C110 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C111 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C112 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C113 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C115 1-126-607-11 ELECT CHIP 47uF 20% 4V
C116 1-126-607-11 ELECT CHIP 47uF 20% 4V
C117 1-126-209-11 ELECT CHIP 100uF 20% 4V
C118 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C119 1-163-106-00 CERAMIC CHIP 36PF 5% 50V
C120 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C121 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C122 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C123 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C124 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C126 1-124-779-00 ELECT CHIP 10uF 20% 16V
C130 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C140 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C141 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C154 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C159 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C161 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C170 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C171 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C180 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C181 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C182 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C183 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C184 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C185 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C186 1-128-065-11 ELECT CHIP 68uF 20% 10V
C187 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-770-706-11 CONNECTOR, FFC/FPC 23P
CN102 1-777-937-11 CONNECTOR, FFC/FPC 16P
< IC >
IC101 8-752-397-42 IC CXD3008Q
IC102 8-759-640-22 IC BA5982FM
IC103 8-752-085-51 IC CXA2568M-T6
IC104 8-759-398-25 IC TC7SH04F(TE85L)
< COIL >
L101 1-414-234-11 FERRITE 0uH
L102 1-410-377-31 INDUCTOR CHIP 4.7uH
< TRANSISTOR >
Q101 8-729-049-31 TRANSISTOR 2SB710A-RTX
< RESISTOR >
R101 1-216-077-00 RES-CHIP 15K 5% 1/10W
R102 1-216-097-11 RES-CHIP 100K 5% 1/10W
R103 1-216-077-00 RES-CHIP 15K 5% 1/10W
R104 1-216-085-00 RES-CHIP 33K 5% 1/10W
R105 1-216-073-00 RES-CHIP 10K 5% 1/10W
R106 1-216-049-11 RES-CHIP 1K 5% 1/10W
R107 1-216-073-00 RES-CHIP 10K 5% 1/10W
R108 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R109 1-216-121-11 RES-CHIP 1M 5% 1/10W
ADDRESS SENOR
